Specifications: Acura RLX (facelift 2017) 3.5 V6 (377 Hp) Hybrid SH-AWD DCT /2017, 2018, 2019, 2020/

2018 Acura RLX (facelift 2017) - Photo 1

Acura RLX (facelift 2017) 3.5 V6 (377 Hp) Hybrid SH-AWD DCT – Full specifications
General information
Brand Acura
Model RLX
Generation RLX (facelift 2017)
Modification (Engine) 3.5 V6 (377 Hp) Hybrid SH-AWD DCT
Start of production 2017 year
End of production 2020 year
Powertrain Architecture FHEV (Full Hybrid Electric Vehicle)
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 11.9 l/100 km
19.77 US mpg
23.74 UK mpg
8.4 km/l
Fuel consumption (economy) – extra urban 12.3 l/100 km
19.12 US mpg
22.97 UK mpg
8.13 km/l
Fuel consumption (economy) – combined 11.9 l/100 km
19.77 US mpg
23.74 UK mpg
8.4 km/l
Fuel Type Petrol (Gasoline)
Weight-to-power ratio 5.3 kg/Hp, 189.7 Hp/tonne
Weight-to-torque ratio 4.3 kg/Nm, 232.5 Nm/tonne
Electric cars and hybrids specs
Battery technology Lithium-ion (Li-Ion)
Electric motor 1
Electric motor power 47 Hp @ 3000 rpm.
Electric motor Torque 147 Nm @ 500-2000 rpm.

108.42 lb.-ft. @ 500-2000 rpm.
Electric motor location Integrated into the transmission
Electric motor 2
Electric motor power 36 Hp @ 4000 rpm.
Electric motor Torque 73 Nm @ 0-2000 rpm.

53.84 lb.-ft. @ 0-2000 rpm.
Electric motor location Rear axle, Transverse
Electric motor 3
Electric motor power 36 Hp @ 4000 rpm.
Electric motor Torque 73 Nm @ 0-2000 rpm.

53.84 lb.-ft. @ 0-2000 rpm.
Electric motor location Rear axle, Transverse
System power 377 Hp
System torque 462 Nm
340.75 lb.-ft.
Internal combustion engine specs
Power 310 Hp @ 6500 rpm.
Power per litre 88.6 Hp/l
Torque 370 Nm @ 4500 rpm.
272.9 lb.-ft. @ 4500 rpm.
Engine layout Front, Transverse
Engine Model/Code J35Y4
Engine displacement 3500 cm3
213.58 cu. in.
Number of cylinders 6
Engine configuration V-engine
Compression ratio 11.5:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Valvetrain SOHC, i-VTEC
Engine oil capacity 4.3 l
4.54 US qt | 3.78 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.9 l
8.35 US qt | 6.95 UK qt

Space, Volume and weights
Kerb Weight 1987 kg
4380.59 lbs.
Trunk (boot) space – minimum 405 l
14.3 cu. ft.
Fuel tank capacity 57 l
15.06 US gal | 12.54 UK gal
Dimensions
Length 5023 mm
197.76 in.
Width 1890 mm
74.41 in.
Height 1465 mm
57.68 in.
Wheelbase 2850 mm
112.2 in.
Front track 1632 mm
64.25 in.
Rear (Back) track 1630 mm
64.17 in.
Ride height (ground clearance) 115 mm
4.53 in.
Minimum turning circle (turning diameter) 12.34 m
40.49 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode. Two electric motors drive the rear wheels.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 7 gears, automatic transmission DCT
Front suspension Double wishbone
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs, 330.2 mm
Rear brakes Disc, 309.88 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 245/40 R19
Wheel rims size 8.0J x 19
