Specifications: Acura TLX I (facelift 2017) 3.5 V6 (294 Hp) Automatic /2017, 2018, 2019, 2020/

2018 Acura TLX I (facelift 2017) - Photo 1

Acura TLX I (facelift 2017) 3.5 V6 (294 Hp) Automatic – Full specifications
General information
Brand Acura
Model TLX
Generation TLX I (facelift 2017)
Modification (Engine) 3.5 V6 (294 Hp) Automatic
Start of production 2017 year
End of production August, 2020 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 4-5
Doors 4
Performance specs
Fuel consumption (economy) – urban 11.8 l/100 km
19.93 US mpg
23.94 UK mpg
8.47 km/l
Fuel consumption (economy) – extra urban 7.3-7.8 l/100 km
32.22 – 30.16 US mpg
38.7 – 36.22 UK mpg
13.7 – 12.82 km/l
Fuel consumption (economy) – combined 9.8-10.2 l/100 km
24 – 23.06 US mpg
28.82 – 27.69 UK mpg
10.2 – 9.8 km/l
Fuel Type Petrol (Gasoline)
Weight-to-power ratio 5.6 kg/Hp, 179.3 Hp/tonne
Weight-to-torque ratio 4.5 kg/Nm, 220.7 Nm/tonne
Engine specs
Power 294 Hp @ 6200 rpm.
Power per litre 84.7 Hp/l
Torque 362 Nm @ 4500 rpm.
267 lb.-ft. @ 4500 rpm.
Maximum engine speed 6800 rpm.
Engine layout Front, Transverse
Engine Model/Code J35Y6
Engine displacement 3471 cm3
211.81 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 89 mm
3.5 in.
Piston Stroke 93 mm
3.66 in.
Compression ratio 11.5:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Naturally aspirated engine
Valvetrain SOHC, i-VTEC
Engine oil capacity 4.3 l
4.54 US qt | 3.78 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8.4 l
8.88 US qt | 7.39 UK qt

Space, Volume and weights
Kerb Weight 1640-1669 kg
3615.58 – 3679.52 lbs.
Trunk (boot) space – minimum 405 l
14.3 cu. ft.
Fuel tank capacity 65 l
17.17 US gal | 14.3 UK gal
Dimensions
Length 4869 mm
191.69 in.
Width 1854 mm
72.99 in.
Height 1448 mm
57.01 in.
Wheelbase 2776 mm
109.29 in.
Front track 1595 mm
62.8 in.
Rear (Back) track 1603 mm
63.11 in.
Ride height (ground clearance) 150 mm
5.91 in.
Drag coefficient (Cd) 0.28
Minimum turning circle (turning diameter) 11.83-12.04 m
38.81 – 39.5 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 9 gears, automatic transmission SportShift
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/50 R18; 245/40 R19
Wheel rims size 7.5J x 18; 8.0J x 19
