Specifications: Alfa Romeo 156 (932) 2.0 JTS (165 Hp) 2000, 2001, 2002, 2003

1997 Alfa Romeo 156 (932) - Photo 1

Alfa Romeo 156 (932) 2.0 JTS (165 Hp) – Full specifications
General information
Brand Alfa Romeo
Model 156
Generation 156 (932)
Modification (Engine) 2.0 JTS (165 Hp)
Start of production 2000 year
End of production 2003 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 12.2 l/100 km
19.28 US mpg
23.15 UK mpg
8.2 km/l
Fuel consumption (economy) – extra urban 6.6 l/100 km
35.64 US mpg
42.8 UK mpg
15.15 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 8.2 sec
Acceleration 0 – 62 mph 8.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.8 sec
Maximum speed 220 km/h
136.7 mph
Weight-to-power ratio 7.8 kg/Hp, 128.4 Hp/tonne
Weight-to-torque ratio 6.2 kg/Nm, 160.3 Nm/tonne
Engine specs
Power 165 Hp @ 6400 rpm.
Power per litre 83.8 Hp/l
Torque 206 Nm @ 3250 rpm.
151.94 lb.-ft. @ 3250 rpm.
Engine layout Front, Transverse
Engine Model/Code 937 A1.000
Engine displacement 1970 cm3
120.22 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 83 mm
3.27 in.
Piston Stroke 91 mm
3.58 in.
Compression ratio 11.3:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Naturally aspirated engine
Engine oil capacity 4.4 l
4.65 US qt | 3.87 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.9 l
7.29 US qt | 6.07 UK qt

Space, Volume and weights
Kerb Weight 1285 kg
2832.94 lbs.
Max. weight 1770 kg
3902.18 lbs.
Max load 485 kg
1069.24 lbs.
Trunk (boot) space – minimum 380 l
13.42 cu. ft.
Fuel tank capacity 63 l
16.64 US gal | 13.86 UK gal
Dimensions
Length 4430 mm
174.41 in.
Width 1755 mm
69.09 in.
Height 1415 mm
55.71 in.
Wheelbase 2595 mm
102.17 in.
Front track 1507 mm
59.33 in.
Rear (Back) track 1494 mm
58.82 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Double wishbone
Rear suspension Several levers and rods
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 205/60 R15
