Specifications: Alfa Romeo 164 (164) 2.0 Twin Spark (148 Hp) /1987, 1988, 1989, 1990/

1987 Alfa Romeo 164 (164) - Photo 1

Alfa Romeo 164 (164) 2.0 Twin Spark (148 Hp) – Full specifications
General information
Brand Alfa Romeo
Model 164
Generation 164 (164)
Modification (Engine) 2.0 Twin Spark (148 Hp)
Start of production 1987 year
End of production 1990 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 10 l/100 km
23.52 US mpg
28.25 UK mpg
10 km/l
Fuel consumption (economy) – extra urban 6.5 l/100 km
36.19 US mpg
43.46 UK mpg
15.38 km/l
Fuel consumption (economy) – combined 8.5 l/100 km
27.67 US mpg
33.23 UK mpg
11.76 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 9.2 sec
Acceleration 0 – 62 mph 9.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.7 sec
Maximum speed 210 km/h
130.49 mph
Weight-to-power ratio 8.1 kg/Hp, 123.3 Hp/tonne
Weight-to-torque ratio 6.5 kg/Nm, 155 Nm/tonne
Engine specs
Power 148 Hp @ 5800 rpm.
Power per litre 75.4 Hp/l
Torque 186 Nm @ 4000 rpm.
137.19 lb.-ft. @ 4000 rpm.
Engine layout Front, Transverse
Engine Model/Code 064.20, 64.103, 064.16
Engine displacement 1962 cm3
119.73 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 84 mm
3.31 in.
Piston Stroke 88.5 mm
3.48 in.
Compression ratio 10:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 5.5 l
5.81 US qt | 4.84 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 9 l
9.51 US qt | 7.92 UK qt

Space, Volume and weights
Kerb Weight 1200 kg
2645.55 lbs.
Max. weight 1625 kg
3582.51 lbs.
Max load 425 kg
936.96 lbs.
Trunk (boot) space – minimum 505 l
17.83 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Dimensions
Length 4555 mm
179.33 in.
Width 1760 mm
69.29 in.
Height 1400 mm
55.12 in.
Wheelbase 2660 mm
104.72 in.
Front track 1515 mm
59.65 in.
Rear (Back) track 1490 mm
58.66 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Wishbone
Rear suspension Several levers and rods
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 195/65 R 15
