Specifications: Aston Martin DB9 Volante 6.0 i V12 (456 Hp) 2004, 2005, 2006, 2007, 2008, 2009, 2010, 2011, 2012

2005 Aston Martin DB9 Volante - Photo 1

Aston Martin DB9 Volante 6.0 i V12 (456 Hp) – Full specifications
General information
Brand Aston Martin
Model DB9
Generation DB9 Volante
Modification (Engine) 6.0 i V12 (456 Hp)
Start of production 2004 year
End of production 2012 year
Powertrain Architecture Internal Combustion engine
Body type Cabriolet
Seats 4
Doors 2
Performance specs
Fuel consumption (economy) – urban 25.2 l/100 km
9.33 US mpg
11.21 UK mpg
3.97 km/l
Fuel consumption (economy) – extra urban 12.2 l/100 km
19.28 US mpg
23.15 UK mpg
8.2 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 4.9 sec
Acceleration 0 – 62 mph 4.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 4.7 sec
Maximum speed 300 km/h
186.41 mph
Weight-to-power ratio 3.8 kg/Hp, 266.7 Hp/tonne
Weight-to-torque ratio 3 kg/Nm, 333.3 Nm/tonne
Engine specs
Power 456 Hp @ 6000 rpm.
Power per litre 76.8 Hp/l
Torque 570 Nm @ 5000 rpm.
420.41 lb.-ft. @ 5000 rpm.
Engine layout Front, Longitudinal
Engine displacement 5935 cm3
362.18 cu. in.
Number of cylinders 12
Engine configuration V-engine
Cylinder Bore 89 mm
3.5 in.
Piston Stroke 79.5 mm
3.13 in.
Compression ratio 10.3:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 10 l
10.57 US qt | 8.8 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 15 l
15.85 US qt | 13.2 UK qt

Space, Volume and weights
Kerb Weight 1710 kg
3769.9 lbs.
Trunk (boot) space – minimum 197 l
6.96 cu. ft.
Fuel tank capacity 85 l
22.45 US gal | 18.7 UK gal
Dimensions
Length 4710 mm
185.43 in.
Width 1875 mm
73.82 in.
Height 1318 mm
51.89 in.
Wheelbase 2740 mm
107.87 in.
Front track 1568 mm
61.73 in.
Rear (Back) track 1562 mm
61.5 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Double wishbone
Rear suspension Double wishbone
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size Front wheel tires: 235/45 R19
Rear wheel tires: 275/35 R19
