Specifications: Audi 80 Avant (B4, Typ 8C) 2.3 E (133 Hp) 1991, 1992, 1993, 1994

1992 Audi 80 Avant (B4, Typ 8C) - Photo 1

Audi 80 Avant (B4, Typ 8C) 2.3 E (133 Hp) – Full specifications
General information
Brand Audi
Model 80
Generation 80 Avant (B4, Typ 8C)
Modification (Engine) 2.3 E (133 Hp)
Start of production September, 1991 year
End of production November, 1994 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 11.8 l/100 km
19.9 US mpg
23.9 UK mpg
8.5 km/l
Fuel consumption (economy) – extra urban 6.6 l/100 km
35.6 US mpg
42.8 UK mpg
15.2 km/l
Fuel consumption (economy) – combined 8.6 l/100 km
27.4 US mpg
32.8 UK mpg
11.6 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 10.1 sec
Acceleration 0 – 62 mph 10.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.6 sec
Maximum speed 195 km/h
121.17 mph
Weight-to-power ratio 9.8 kg/Hp, 101.5 Hp/tonne
Weight-to-torque ratio 7 kg/Nm, 142 Nm/tonne
Engine specs
Power 133 Hp @ 5500 rpm.
Power per litre 57.6 Hp/l
Torque 186 Nm @ 4000 rpm.
137.19 lb.-ft. @ 4000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code NG
Engine displacement 2309 cm3
140.9 cu. in.
Number of cylinders 5
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 86.4 mm
3.4 in.
Compression ratio 10:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain OHC
Engine oil capacity 4 l
4.23 US qt | 3.52 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8.5 l
8.98 US qt | 7.48 UK qt

Space, Volume and weights
Kerb Weight 1310 kg
2888.06 lbs.
Max. weight 1860 kg
4100.6 lbs.
Max load 550 kg
1212.54 lbs.
Trunk (boot) space – minimum 370 l
13.07 cu. ft.
Trunk (boot) space – maximum 1200 l
42.38 cu. ft.
Fuel tank capacity 65 l
17.17 US gal | 14.3 UK gal
Dimensions
Length 4482 mm
176.46 in.
Width 1695 mm
66.73 in.
Height 1408 mm
55.43 in.
Wheelbase 2612 mm
102.83 in.
Front track 1448 mm
57.01 in.
Rear (Back) track 1471 mm
57.91 in.
Ride height (ground clearance) 135 mm
5.31 in.
Drag coefficient (Cd) 0.34
Minimum turning circle (turning diameter) 11.2 m
36.75 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Wishbone
Rear suspension Several levers and rods
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 195/65 R15
Wheel rims size 15
