Specifications: Audi 90 (B3, Typ 89,89Q,8A) 2.3 E CAT (136 Hp) 1987, 1988

1987 Audi 90 (B3, Typ 89,89Q,8A) - Photo 1

Audi 90 (B3, Typ 89,89Q,8A) 2.3 E CAT (136 Hp) – Full specifications
General information
Brand Audi
Model 90
Generation 90 (B3, Typ 89,89Q,8A)
Modification (Engine) 2.3 E CAT (136 Hp)
Start of production 1987 year
End of production 1988 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 11.8 l/100 km
19.9 US mpg
23.9 UK mpg
8.5 km/l
Fuel consumption (economy) – extra urban 6.3 l/100 km
37.3 US mpg
44.8 UK mpg
15.9 km/l
Fuel consumption (economy) – combined 8.3 l/100 km
28.3 US mpg
34 UK mpg
12 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 8.9 sec
Acceleration 0 – 62 mph 8.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.5 sec
Maximum speed 206 km/h
128 mph
Weight-to-power ratio 8.2 kg/Hp, 122.5 Hp/tonne
Weight-to-torque ratio 5.9 kg/Nm, 170.3 Nm/tonne
Engine specs
Power 136 Hp @ 5500 rpm.
Power per litre 58.9 Hp/l
Torque 189 Nm @ 4500 rpm.
139.4 lb.-ft. @ 4500 rpm.
Engine layout Front, Longitudinal
Engine Model/Code NG
Engine displacement 2309 cm3
140.9 cu. in.
Number of cylinders 5
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 86.4 mm
3.4 in.
Compression ratio 10:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain OHC
Engine oil capacity 4 l
4.23 US qt | 3.52 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8.5 l
8.98 US qt | 7.48 UK qt

Space, Volume and weights
Kerb Weight 1110 kg
2447.13 lbs.
Max. weight 1570 kg
3461.26 lbs.
Max load 460 kg
1014.13 lbs.
Trunk (boot) space – minimum 425 l
15.01 cu. ft.
Fuel tank capacity 68 l
17.96 US gal | 14.96 UK gal
Dimensions
Length 4393 mm
172.95 in.
Width 1695 mm
66.73 in.
Height 1397 mm
55 in.
Wheelbase 2546 mm
100.24 in.
Front track 1411 mm
55.55 in.
Rear (Back) track 1432 mm
56.38 in.
Drag coefficient (Cd) 0.31
Minimum turning circle (turning diameter) 10.3 m
33.79 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front brakes Disc
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 195/60 R14
Wheel rims size 14
