Specifications: Audi A1 Sportback (8X facelift 2014) 1.8 TFSI (192 Hp) S tronic 2014, 2015, 2016, 2017, 2018

2014 Audi A1 Sportback (8X facelift 2014) - Photo 1

Audi A1 Sportback (8X facelift 2014) 1.8 TFSI (192 Hp) S tronic – Full specifications
General information
Brand Audi
Model A1
Generation A1 Sportback (8X facelift 2014)
Modification (Engine) 1.8 TFSI (192 Hp) S tronic
Start of production 2014 year
End of production 2018 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 7.1-7.4 l/100 km
33.1 – 31.8 US mpg
39.8 – 38.2 UK mpg
14.1 – 13.5 km/l
Fuel consumption (economy) – extra urban 4.7-4.9 l/100 km
50 – 48 US mpg
60.1 – 57.6 UK mpg
21.3 – 20.4 km/l
Fuel consumption (economy) – combined 5.6-5.8 l/100 km
42 – 40.6 US mpg
50.4 – 48.7 UK mpg
17.9 – 17.2 km/l
CO2 emissions 134 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 6.9 sec
Acceleration 0 – 62 mph 6.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.6 sec
Maximum speed 234 km/h
145.4 mph
Emission standard Euro 6
Weight-to-power ratio 6.3 kg/Hp, 159.3 Hp/tonne
Weight-to-torque ratio 4.8 kg/Nm, 207.5 Nm/tonne
Engine specs
Power 192 Hp @ 5400 rpm.
Power per litre 106.8 Hp/l
Torque 250 Nm @ 1250-5300 rpm.
184.39 lb.-ft. @ 1250-5300 rpm.
Engine layout Front, Transverse
Engine Model/Code EA888 / DAJB
Engine displacement 1798 cm3
109.72 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 84.1 mm
3.31 in.
Compression ratio 9.6:1
Number of valves per cylinder 4
Fuel injection system Direct injection and Multi-port manifold injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 5.2 l
5.49 US qt | 4.58 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8.5 l
8.98 US qt | 7.48 UK qt
Engine systems Start & Stop System

Space, Volume and weights
Kerb Weight 1205 kg
2656.57 lbs.
Max. weight 1705 kg
3758.88 lbs.
Max load 500 kg
1102.31 lbs.
Trunk (boot) space – minimum 270 l
9.53 cu. ft.
Trunk (boot) space – maximum 920 l
32.49 cu. ft.
Fuel tank capacity 45 l
11.89 US gal | 9.9 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (8%) 1200 kg
2645.55 lbs.
Permitted trailer load with brakes (12%) 1200 kg
2645.55 lbs.
Permitted trailer load without brakes 640 kg
1410.96 lbs.
Permitted towbar download 50 kg
110.23 lbs.
Dimensions
Length 3973 mm
156.42 in.
Width 1746 mm
68.74 in.
Width including mirrors 1906 mm
75.04 in.
Height 1422 mm
55.98 in.
Wheelbase 2469 mm
97.2 in.
Front track 1477 mm
58.15 in.
Rear (Back) track 1471 mm
57.91 in.
Front overhang 813 mm
32.01 in.
Rear overhang 691 mm
27.2 in.
Drag coefficient (Cd) 0.32
Minimum turning circle (turning diameter) 10.6 m
34.78 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 7 gears, automatic transmission S tronic
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Semi-independent, coil spring, Torsion
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/45 R16
Wheel rims size 7J x 16
