Specifications: Audi A3 Sportback (8PA, facelift 2008) 2.0 TFSI (200 Hp) S tronic 2008, 2009, 2010, 2011, 2012, 2013

2008 Audi A3 Sportback (8PA, facelift 2008) - Photo 1

Audi A3 Sportback (8PA, facelift 2008) 2.0 TFSI (200 Hp) S tronic – Full specifications
General information
Brand Audi
Model A3
Generation A3 Sportback (8PA, facelift 2008)
Modification (Engine) 2.0 TFSI (200 Hp) S tronic
Start of production 2008 year
End of production 2013 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 9.8 l/100 km
24 US mpg
28.82 UK mpg
10.2 km/l
Fuel consumption (economy) – extra urban 5.7 l/100 km
41.27 US mpg
49.56 UK mpg
17.54 km/l
Fuel consumption (economy) – combined 7.2 l/100 km
32.67 US mpg
39.23 UK mpg
13.89 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 6.9 sec
Acceleration 0 – 62 mph 6.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.6 sec
Maximum speed 238 km/h
147.89 mph
Emission standard Euro 4
Weight-to-power ratio 6.9 kg/Hp, 146 Hp/tonne
Weight-to-torque ratio 4.9 kg/Nm, 204.4 Nm/tonne
Engine specs
Power 200 Hp @ 5100-6000 rpm.
Power per litre 100.8 Hp/l
Torque 280 Nm @ 1700-5000 rpm.
206.52 lb.-ft. @ 1700-5000 rpm.
Engine layout Front, Transverse
Engine Model/Code BWA, CAWB, CBFA, CCZA
Engine displacement 1984 cm3
121.07 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 92.8 mm
3.65 in.
Compression ratio 11.5:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4.6 l
4.86 US qt | 4.05 UK qt
Engine oil specification Log in to see.Log in to see.

Space, Volume and weights
Kerb Weight 1370 kg
3020.33 lbs.
Max. weight 1930 kg
4254.92 lbs.
Max load 560 kg
1234.59 lbs.
Trunk (boot) space – minimum 552 l
19.49 cu. ft.
Trunk (boot) space – maximum 1104 l
38.99 cu. ft.
Fuel tank capacity 55 l
14.53 US gal | 12.1 UK gal
Dimensions
Length 4292 mm
168.98 in.
Width 1765 mm
69.49 in.
Height 1423 mm
56.02 in.
Wheelbase 2578 mm
101.5 in.
Front track 1534 mm
60.39 in.
Rear (Back) track 1507 mm
59.33 in.
Ride height (ground clearance) 110 mm
4.33 in.
Drag coefficient (Cd) 0.31
Minimum turning circle (turning diameter) 10.7 m
35.1 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission
Front suspension Spring Strut
Rear suspension Transverse stabilizer
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 205/55 R16; 225/45 R17
Wheel rims size 6.5J x 16; 7.5J x 17
