Specifications: Audi A3 Sportback (8V) 2.0 TDI (150 Hp) clean diesel S-tronic 2013, 2014, 2015, 2016

2013 Audi A3 Sportback (8V) - Photo 1

Audi A3 Sportback (8V) 2.0 TDI (150 Hp) clean diesel S-tronic – Full specifications
General information
Brand Audi
Model A3
Generation A3 Sportback (8V)
Modification (Engine) 2.0 TDI (150 Hp) clean diesel S-tronic
Start of production 2013 year
End of production 2016 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 5.4 l/100 km
43.56 US mpg
52.31 UK mpg
18.52 km/l
Fuel consumption (economy) – extra urban 4.1 l/100 km
57.37 US mpg
68.9 UK mpg
24.39 km/l
Fuel consumption (economy) – combined 4.5 l/100 km
52.27 US mpg
62.77 UK mpg
22.22 km/l
CO2 emissions 116 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 8.3 sec
Acceleration 0 – 62 mph 8.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.9 sec
Maximum speed 218 km/h
135.46 mph
Emission standard Euro 6
Weight-to-power ratio 8.8 kg/Hp, 113.6 Hp/tonne
Weight-to-torque ratio 4.1 kg/Nm, 242.4 Nm/tonne
Engine specs
Power 150 Hp @ 3500-4000 rpm.
Power per litre 76.2 Hp/l
Torque 320 Nm @ 1750-3000 rpm.
236.02 lb.-ft. @ 1750-3000 rpm.
Engine layout Front, Transverse
Engine Model/Code CRBC, CRLB, CRUA, DBGA, DEJA, DCYA
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 16.2:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4.7 l
4.97 US qt | 4.14 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1320 kg
2910.1 lbs.
Max. weight 1880 kg
4144.69 lbs.
Max load 560 kg
1234.59 lbs.
Trunk (boot) space – minimum 380 l
13.42 cu. ft.
Trunk (boot) space – maximum 1220 l
43.08 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (8%) 1800 kg
3968.32 lbs.
Permitted trailer load with brakes (12%) 1600 kg
3527.4 lbs.
Permitted trailer load without brakes 690 kg
1521.19 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4310 mm
169.69 in.
Width 1786 mm
70.31 in.
Width including mirrors 1966 mm
77.4 in.
Height 1426 mm
56.14 in.
Wheelbase 2636 mm
103.78 in.
Front track 1536 mm
60.47 in.
Rear (Back) track 1506 mm
59.29 in.
Front overhang 869 mm
34.21 in.
Rear overhang 805 mm
31.69 in.
Drag coefficient (Cd) 0.31
Minimum turning circle (turning diameter) 10.9 m
35.76 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, automatic transmission S-tronic
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/55 R16
Wheel rims size 6.5J x 16
