Specifications: Audi A3 Sportback (8V, facelift 2016) 1.6 TDI (110 Hp) S tronic 2016, 2017

2017 Audi A3 Sportback (8V, facelift 2016) - Photo 1

Audi A3 Sportback (8V, facelift 2016) 1.6 TDI (110 Hp) S tronic – Full specifications
General information
Brand Audi
Model A3
Generation A3 Sportback (8V, facelift 2016)
Modification (Engine) 1.6 TDI (110 Hp) S tronic
Start of production 2016 year
End of production 2017 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 4.3-4.6 l/100 km
54.7 – 51.13 US mpg
65.69 – 61.41 UK mpg
23.26 – 21.74 km/l
Fuel consumption (economy) – extra urban 3.5-3.8 l/100 km
67.2 – 61.9 US mpg
80.71 – 74.34 UK mpg
28.57 – 26.32 km/l
Fuel consumption (economy) – combined 3.8-4.1 l/100 km
61.9 – 57.37 US mpg
74.34 – 68.9 UK mpg
26.32 – 24.39 km/l
CO2 emissions 99-107 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 10.7 sec
Acceleration 0 – 62 mph 10.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.2 sec
Maximum speed 200 km/h
124.27 mph
Emission standard Euro 6
Weight-to-power ratio 11.7 kg/Hp, 85.6 Hp/tonne
Weight-to-torque ratio 5.1 kg/Nm, 194.6 Nm/tonne
Engine specs
Power 110 Hp @ 3200-4000 rpm.
Power per litre 68.8 Hp/l
Torque 250 Nm @ 1500-3000 rpm.
184.39 lb.-ft. @ 1500-3000 rpm.
Engine layout Front, Transverse
Engine Model/Code CRKB, CXXB, DBKA
Engine displacement 1598 cm3
97.52 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 79.5 mm
3.13 in.
Piston Stroke 80.5 mm
3.17 in.
Compression ratio 16.2:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4.7 l
4.97 US qt | 4.14 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 12 l
12.68 US qt | 10.56 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1285 kg
2832.94 lbs.
Max. weight 1845 kg
4067.53 lbs.
Max load 560 kg
1234.59 lbs.
Trunk (boot) space – minimum 380 l
13.42 cu. ft.
Trunk (boot) space – maximum 1220 l
43.08 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (8%) 1700 kg
3747.86 lbs.
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 680 kg
1499.14 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4313 mm
169.8 in.
Width 1785 mm
70.28 in.
Width including mirrors 1966 mm
77.4 in.
Height 1426 mm
56.14 in.
Wheelbase 2637 mm
103.82 in.
Front track 1543 mm
60.75 in.
Rear (Back) track 1514 mm
59.61 in.
Front overhang 870 mm
34.25 in.
Rear overhang 806 mm
31.73 in.
Drag coefficient (Cd) 0.31
Minimum turning circle (turning diameter) 10.9 m
35.76 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 7 gears, automatic transmission Stronic
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Semi-independent, coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/55 R16; 225/45 R17; 225/40 R18
Wheel rims size 6.5J x 16; 17; 18
