Specifications: Audi A3 Sportback (8V, facelift 2016) 30 TDI (116 Hp) 2018, 2019, 2020

2017 Audi A3 Sportback (8V, facelift 2016) - Photo 1

Audi A3 Sportback (8V, facelift 2016) 30 TDI (116 Hp) – Full specifications
General information
Brand Audi
Model A3
Generation A3 Sportback (8V, facelift 2016)
Modification (Engine) 30 TDI (116 Hp)
Start of production 2018 year
End of production 2020 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 5.0-5.2 l/100 km
47.04 – 45.23 US mpg
56.5 – 54.32 UK mpg
20 – 19.23 km/l
Fuel consumption (economy) – extra urban 4.0-4.1 l/100 km
58.8 – 57.37 US mpg
70.62 – 68.9 UK mpg
25 – 24.39 km/l
Fuel consumption (economy) – combined 4.4-4.5 l/100 km
53.46 – 52.27 US mpg
64.2 – 62.77 UK mpg
22.73 – 22.22 km/l
CO2 emissions 114-118 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 10.4 sec
Acceleration 0 – 62 mph 10.4 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.9 sec
Maximum speed 205 km/h
127.38 mph
Emission standard Euro 6d – TEMP
Weight-to-power ratio 11.1 kg/Hp, 89.9 Hp/tonne
Weight-to-torque ratio 5.2 kg/Nm, 193.8 Nm/tonne
Engine specs
Power 116 Hp @ 3250-4000 rpm.
Power per litre 72.6 Hp/l
Torque 250 Nm @ 1750-3200 rpm.
184.39 lb.-ft. @ 1750-3200 rpm.
Engine layout Front, Transverse
Engine Model/Code DGTE
Engine displacement 1598 cm3
97.52 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 79.5 mm
3.13 in.
Piston Stroke 80.5 mm
3.17 in.
Compression ratio 16.2:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4.7 l
4.97 US qt | 4.14 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 12 l
12.68 US qt | 10.56 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1290 kg
2843.96 lbs.
Max. weight 1875 kg
4133.67 lbs.
Max load 585 kg
1289.7 lbs.
Trunk (boot) space – minimum 380 l
13.42 cu. ft.
Trunk (boot) space – maximum 1220 l
43.08 cu. ft.
Fuel tank capacity 50 l
13.21 US gal | 11 UK gal
AdBlue tank 13 l
3.43 US gal | 2.86 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (8%) 1700 kg
3747.86 lbs.
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 680 kg
1499.14 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4313 mm
169.8 in.
Width 1785 mm
70.28 in.
Width including mirrors 1966 mm
77.4 in.
Height 1461 mm
57.52 in.
Wheelbase 2637 mm
103.82 in.
Front track 1543 mm
60.75 in.
Rear (Back) track 1514 mm
59.61 in.
Drag coefficient (Cd) 0.32
Minimum turning circle (turning diameter) 10.9 m
35.76 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent type McPherson
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/55 R16; 225/45 R17; 225/40 R18
Wheel rims size 6.5J x 16
