| General information | |
|---|---|
| Brand | Audi |
| Model | A3 |
| Generation | A3 Sportback (8Y, facelift 2024) |
| Modification (Engine) | 40 TFSI e (204 Hp) Plug-in Hybrid S tronic |
| Start of production | October, 2024 year |
| Powertrain Architecture | PHEV (Plug-in Hybrid Electric Vehicle) |
| Body type | Hatchback |
| Seats | 5 |
| Doors | 5 |
| Performance specs | |
| Combined fuel consumption (WLTP) | 0.3-0.4 l/100 km 784.05 – 588.04 US mpg 941.6 – 706.2 UK mpg 333.33 – 250 km/l |
| CO2 emissions (WLTP) | 6-8 g/km |
| Fuel Type | Petrol / electricity |
| Acceleration 0 – 100 km/h | 7.4 sec |
| Acceleration 0 – 62 mph | 7.4 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 7 sec |
| Maximum speed | 225 km/h 139.81 mph |
| Emission standard | Euro 6e |
| Weight-to-power ratio | 7.8 kg/Hp, 127.5 Hp/tonne |
| Weight-to-torque ratio | 4.6 kg/Nm, 218.8 Nm/tonne |
| Electric cars and hybrids specs | |
| Gross battery capacity | 25.7 kWh |
| Net (usable) battery capacity | 19.7 kWh |
| Battery voltage | 400 V |
| Battery technology | Lithium nickel manganese cobalt oxides (Li-NMC) |
| Battery location | Below the floor, under the rear seats |
| Recuperation output | 43 kW |
| All-electric range (WLTP) | 126-143 km 78.29 – 88.86 mi |
| Average Energy consumption (WLTP) | 14.6-16.2 kWh/100 km
23.5 – 26.07 kWh/100 mi |
| Max speed (electric) | 140 km/h
86.99 mph |
| Charging ports |  Log in to see. |
| Electric motor 1 | |
| Electric motor power | 116 Hp |
| Electric motor Torque | 330 Nm
243.4 lb.-ft. |
| Electric motor location | Between the combustion engine and the transmission |
| Electric motor type | Synchronous |
| System power | 204 Hp |
| System torque | 350 Nm 258.15 lb.-ft. |
| Internal combustion engine specs | |
| Power | 150 Hp @ 5000-6000 rpm. |
| Power per litre | 100.1 Hp/l |
| Torque | 250 Nm @ 1500-4000 rpm. 184.39 lb.-ft. @ 1500-4000 rpm. |
| Engine layout | Front, Transverse |
| Engine Model/Code | EA211 evo2 |
| Engine displacement | 1498 cm3 91.41 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 74.5 mm 2.93 in. |
| Piston Stroke | 85.9 mm 3.38 in. |
| Compression ratio | 11.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Direct injection |
| Engine aspiration | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine oil capacity | 4.3 l 4.54 US qt | 3.78 UK qt |
| Coolant | 16.2 l 17.12 US qt | 14.25 UK qt |
| Engine systems | Start & Stop System Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1600 kg 3527.4 lbs. |
| Max. weight | 2095-2110 kg 4618.68 – 4651.75 lbs. |
| Max load | 495-510 kg 1091.29 – 1124.36 lbs. |
| Trunk (boot) space – minimum | 280 l 9.89 cu. ft. |
| Trunk (boot) space – maximum | 1100 l 38.85 cu. ft. |
| Fuel tank capacity | 40 l 10.57 US gal | 8.8 UK gal |
| Max. roof load | 75 kg 165.35 lbs. |
| Permitted trailer load with brakes (8%) | 1700 kg 3747.86 lbs. |
| Permitted trailer load with brakes (12%) | 1400 kg 3086.47 lbs. |
| Permitted trailer load without brakes | 750 kg 1653.47 lbs. |
| Permitted towbar download | 80 kg 176.37 lbs. |
| Dimensions | |
| Length | 4352 mm 171.34 in. |
| Width | 1816 mm 71.5 in. |
| Width including mirrors | 1984 mm 78.11 in. |
| Height | 1451 mm 57.13 in. |
| Wheelbase | 2630 mm 103.54 in. |
| Front track | 1542-1554 mm 60.71 – 61.18 in. |
| Rear (Back) track | 1513-1526 mm 59.57 – 60.08 in. |
| Front overhang | 906 mm 35.67 in. |
| Rear overhang | 816 mm 32.13 in. |
| Drag coefficient (Cd) | 0.30 |
| Minimum turning circle (turning diameter) | 11.1 m 36.42 ft. |
| Approach angle | 14.1° |
| Departure angle | 25.3° |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work in full electric or mixed mode. |
| Drive wheel | Front wheel drive |
| Number of gears and type of gearbox | 6 gears, automatic transmission S tronic |
| Front suspension | Independent, type McPherson with coil spring and anti-roll bar |
| Rear suspension | Independent multi-link spring suspension with stabilizer |
| Front brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Power steering | Electric Steering |
| Tires size | 225/45 R17 |
| Wheel rims size | 8J x 17 |
