Specifications: Audi A4 allroad (B8 8K, facelift 2011) 2.0 TDI (177 Hp) quattro S tronic 2011, 2012, 2013, 2014, 2015

2011 Audi A4 allroad (B8 8K, facelift 2011) - Photo 1

Audi A4 allroad (B8 8K, facelift 2011) 2.0 TDI (177 Hp) quattro S tronic – Full specifications
General information
Brand Audi
Model A4
Generation A4 allroad (B8 8K, facelift 2011)
Modification (Engine) 2.0 TDI (177 Hp) quattro S tronic
Start of production 2011 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate), Crossover
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 7 l/100 km
33.6 US mpg
40.35 UK mpg
14.29 km/l
Fuel consumption (economy) – extra urban 5.4 l/100 km
43.56 US mpg
52.31 UK mpg
18.52 km/l
Fuel consumption (economy) – combined 6 l/100 km
39.2 US mpg
47.08 UK mpg
16.67 km/l
CO2 emissions 156 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 8.1 sec
Acceleration 0 – 62 mph 8.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.7 sec
Maximum speed 210 km/h
130.49 mph
Emission standard Euro 5
Weight-to-power ratio 9.4 kg/Hp, 106 Hp/tonne
Weight-to-torque ratio 4.4 kg/Nm, 227.5 Nm/tonne
Engine specs
Power 177 Hp @ 4200 rpm.
Power per litre 89.9 Hp/l
Torque 380 Nm @ 1750-2500 rpm.
280.27 lb.-ft. @ 1750-2500 rpm.
Engine layout Front, Longitudinal
Engine Model/Code CGLC
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 16:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 5 l
5.28 US qt | 4.4 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1670 kg
3681.72 lbs.
Max. weight 2240 kg
4938.35 lbs.
Max load 570 kg
1256.63 lbs.
Trunk (boot) space – minimum 490 l
17.3 cu. ft.
Trunk (boot) space – maximum 1430 l
50.5 cu. ft.
Fuel tank capacity 61 l
16.11 US gal | 13.42 UK gal
Max. roof load 90 kg
198.42 lbs.
Permitted trailer load with brakes (8%) 2100 kg
4629.71 lbs.
Permitted trailer load with brakes (12%) 1900 kg
4188.78 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 80 kg
176.37 lbs.
Dimensions
Length 4721 mm
185.87 in.
Width 1841 mm
72.48 in.
Width including mirrors 2003 mm
78.86 in.
Height 1495 mm
58.86 in.
Wheelbase 2805 mm
110.43 in.
Front track 1583 mm
62.32 in.
Rear (Back) track 1574 mm
61.97 in.
Front overhang 883 mm
34.76 in.
Rear overhang 1033 mm
40.67 in.
Drag coefficient (Cd) 0.34
Minimum turning circle (turning diameter) 11.5 m
37.73 ft.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 7 gears, automatic transmission S tronic
Front suspension Independent multi-link suspension
Rear suspension Independent on trapezoidal lever
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/55 R17
Wheel rims size 8J x 17
