Specifications: Audi A4 allroad (B9 8W, facelift 2019) 45 TDI V6 (231 Hp) quattro tiptronic 2019

2020 Audi A4 allroad (B9 8W, facelift 2019) - Photo 1

Audi A4 allroad (B9 8W, facelift 2019) 45 TDI V6 (231 Hp) quattro tiptronic – Full specifications
General information
Brand Audi
Model A4
Generation A4 allroad (B9 8W, facelift 2019)
Modification (Engine) 45 TDI V6 (231 Hp) quattro tiptronic
Start of production May, 2019 year
End of production December, 2019 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate), Crossover
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 7.0-7.2 l/100 km
33.6 – 32.67 US mpg
40.35 – 39.23 UK mpg
14.29 – 13.89 km/l
Fuel consumption (economy) – extra urban 5.4-5.5 l/100 km
43.56 – 42.77 US mpg
52.31 – 51.36 UK mpg
18.52 – 18.18 km/l
Fuel consumption (economy) – combined 6.0-6.1 l/100 km
39.2 – 38.56 US mpg
47.08 – 46.31 UK mpg
16.67 – 16.39 km/l
CO2 emissions 157-161 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 6.2 sec
Acceleration 0 – 62 mph 6.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 5.9 sec
Maximum speed 241 km/h
149.75 mph
Emission standard Euro 6d-TEMP-EVAP-ISC
Weight-to-power ratio 7.6 kg/Hp, 131.6 Hp/tonne
Weight-to-torque ratio 3.5 kg/Nm, 284.9 Nm/tonne
Engine specs
Power 231 Hp @ 3250-4750 rpm.
Power per litre 77.9 Hp/l
Torque 500 Nm @ 1750-3250 rpm.
368.78 lb.-ft. @ 1750-3250 rpm.
Engine layout Front, Longitudinal
Engine Model/Code DCPE
Engine displacement 2967 cm3
181.06 cu. in.
Number of cylinders 6
Engine configuration V-engine
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 6.1 l
6.45 US qt | 5.37 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1755 kg
3869.11 lbs.
Max. weight 2350 kg
5180.86 lbs.
Max load 595 kg
1311.75 lbs.
Trunk (boot) space – minimum 495 l
17.48 cu. ft.
Trunk (boot) space – maximum 1495 l
52.8 cu. ft.
Fuel tank capacity 58 l
15.32 US gal | 12.76 UK gal
AdBlue tank 12 l
3.17 US gal | 2.64 UK gal
Max. roof load 90 kg
198.42 lbs.
Permitted trailer load with brakes (8%) 2000 kg
4409.25 lbs.
Permitted trailer load with brakes (12%) 1800 kg
3968.32 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 80 kg
176.37 lbs.
Dimensions
Length 4762 mm
187.48 in.
Width 1847 mm
72.72 in.
Width including mirrors 2022 mm
79.61 in.
Height 1493 mm
58.78 in.
Wheelbase 2818 mm
110.94 in.
Front track 1578 mm
62.13 in.
Rear (Back) track 1566 mm
61.65 in.
Front overhang 898 mm
35.35 in.
Rear overhang 1046 mm
41.18 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 8 gears, automatic transmission tiptronic
Front suspension Independent multi-link suspension
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/55 R17 97Y
Wheel rims size 7.5J x 17
