Specifications: Audi A4 Avant (B5, Typ 8D) 2.8 V6 (174 Hp) 1996, 1997

1996 Audi A4 Avant (B5, Typ 8D) - Photo 1

Audi A4 Avant (B5, Typ 8D) 2.8 V6 (174 Hp) – Full specifications
General information
Brand Audi
Model A4
Generation A4 Avant (B5, Typ 8D)
Modification (Engine) 2.8 V6 (174 Hp)
Start of production 1996 year
End of production 1997 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel Type Petrol (Gasoline)
Maximum speed 230 km/h
142.92 mph
Engine specs
Power 174 Hp @ 5500 rpm.
Power per litre 62.8 Hp/l
Torque 250 Nm @ 3000 rpm.
184.39 lb.-ft. @ 3000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code AAH
Engine displacement 2771 cm3
169.1 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 86.4 mm
3.4 in.
Compression ratio 10.3:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Engine oil capacity 5 l
5.28 US qt | 4.4 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.5 l
6.87 US qt | 5.72 UK qt

Space, Volume and weights
Trunk (boot) space – minimum 390 l
13.77 cu. ft.
Trunk (boot) space – maximum 1250 l
44.14 cu. ft.
Fuel tank capacity 62 l
16.38 US gal | 13.64 UK gal
Dimensions
Length 4478 mm
176.3 in.
Width 1733 mm
68.23 in.
Height 1415 mm
55.71 in.
Wheelbase 2622 mm
103.23 in.
Front track 1498 mm
58.98 in.
Rear (Back) track 1479 mm
58.23 in.
Drag coefficient (Cd) 0.31
Minimum turning circle (turning diameter) 11.1 m
36.42 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
