Specifications: Audi A4 Avant (B5, Typ 8D, facelift 1999) 1.9 TDI (115 Hp) Tiptronic 1999, 2000, 2001

1999 Audi A4 Avant (B5, Typ 8D, facelift 1999) - Photo 1

Audi A4 Avant (B5, Typ 8D, facelift 1999) 1.9 TDI (115 Hp) Tiptronic – Full specifications
General information
Brand Audi
Model A4
Generation A4 Avant (B5, Typ 8D, facelift 1999)
Modification (Engine) 1.9 TDI (115 Hp) Tiptronic
Start of production 1999 year
End of production September, 2001 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 9.6 l/100 km
24.5 US mpg
29.43 UK mpg
10.42 km/l
Fuel consumption (economy) – extra urban 5.3 l/100 km
44.38 US mpg
53.3 UK mpg
18.87 km/l
Fuel consumption (economy) – combined 6.8 l/100 km
34.59 US mpg
41.54 UK mpg
14.71 km/l
Fuel Type Diesel
Acceleration 0 – 100 km/h 12.2 sec
Acceleration 0 – 62 mph 12.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.6 sec
Maximum speed 192 km/h
119.3 mph
Weight-to-power ratio 11.9 kg/Hp, 83.9 Hp/tonne
Weight-to-torque ratio 4.8 kg/Nm, 208 Nm/tonne
Engine specs
Power 115 Hp @ 4000 rpm.
Power per litre 60.7 Hp/l
Torque 285 Nm @ 1900 rpm.
210.21 lb.-ft. @ 1900 rpm.
Engine layout Front, Longitudinal
Engine Model/Code AJM, ATJ
Engine displacement 1896 cm3
115.7 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 79.5 mm
3.13 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 19.5:1
Number of valves per cylinder 2
Fuel injection system Pump-nozzle (Unit Injector)
Engine aspiration Turbocharger
Valvetrain OHC
Engine oil capacity 3.8 l
4.02 US qt | 3.34 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.5 l
6.87 US qt | 5.72 UK qt

Space, Volume and weights
Kerb Weight 1370 kg
3020.33 lbs.
Max. weight 1920 kg
4232.88 lbs.
Max load 550 kg
1212.54 lbs.
Trunk (boot) space – minimum 390 l
13.77 cu. ft.
Trunk (boot) space – maximum 1250 l
44.14 cu. ft.
Fuel tank capacity 62 l
16.38 US gal | 13.64 UK gal
Dimensions
Length 4479 mm
176.34 in.
Width 1733 mm
68.23 in.
Height 1417 mm
55.79 in.
Wheelbase 2622 mm
103.23 in.
Front track 1498 mm
58.98 in.
Rear (Back) track 1479 mm
58.23 in.
Drag coefficient (Cd) 0.31
Minimum turning circle (turning diameter) 11.1 m
36.42 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, automatic transmission Tiptronic
Front suspension Independent multi-link suspension
Rear suspension Suspension with traction connecting levers
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 195/65 R15
Wheel rims size 6J x 15
