Specifications: Audi A4 Avant (B5, Typ 8D, facelift 1999) 2.4 V6 30V (165 Hp) quattro 1999, 2000

1999 Audi A4 Avant (B5, Typ 8D, facelift 1999) - Photo 1

Audi A4 Avant (B5, Typ 8D, facelift 1999) 2.4 V6 30V (165 Hp) quattro – Full specifications
General information
Brand Audi
Model A4
Generation A4 Avant (B5, Typ 8D, facelift 1999)
Modification (Engine) 2.4 V6 30V (165 Hp) quattro
Start of production 1999 year
End of production September, 2000 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 14.7 l/100 km
16 US mpg
19.22 UK mpg
6.8 km/l
Fuel consumption (economy) – extra urban 7.9 l/100 km
29.77 US mpg
35.76 UK mpg
12.66 km/l
Fuel consumption (economy) – combined 10.4 l/100 km
22.62 US mpg
27.16 UK mpg
9.62 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 8.6 sec
Acceleration 0 – 62 mph 8.6 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.2 sec
Maximum speed 220 km/h
136.7 mph
Weight-to-power ratio 8.9 kg/Hp, 112.6 Hp/tonne
Weight-to-torque ratio 6.4 kg/Nm, 157 Nm/tonne
Engine specs
Power 165 Hp @ 6000 rpm.
Power per litre 69 Hp/l
Torque 230 Nm @ 3200 rpm.
169.64 lb.-ft. @ 3200 rpm.
Engine layout Front, Longitudinal
Engine Model/Code AML, APS, ARJ
Engine displacement 2393 cm3
146.03 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 77.4 mm
3.05 in.
Compression ratio 10.5:1
Number of valves per cylinder 5
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 6 l
6.34 US qt | 5.28 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8 l
8.45 US qt | 7.04 UK qt

Space, Volume and weights
Kerb Weight 1465 kg
3229.77 lbs.
Max. weight 2015 kg
4442.31 lbs.
Max load 550 kg
1212.54 lbs.
Trunk (boot) space – minimum 390 l
13.77 cu. ft.
Trunk (boot) space – maximum 1250 l
44.14 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
Dimensions
Length 4479 mm
176.34 in.
Width 1733 mm
68.23 in.
Height 1417 mm
55.79 in.
Wheelbase 2607 mm
102.64 in.
Front track 1498 mm
58.98 in.
Rear (Back) track 1475 mm
58.07 in.
Drag coefficient (Cd) 0.32
Minimum turning circle (turning diameter) 11.1 m
36.42 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives permanently the four wheels of the vehicle.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Double wishbone
Rear suspension Suspension with traction connecting levers
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 195/65 R15
Wheel rims size 15
