Specifications: Audi A4 Avant (B6 8E) 2.0i 20V (130 Hp) Multitronic 2001, 2002, 2003, 2004

2002 Audi A4 Avant (B6 8E) - Photo 1

Audi A4 Avant (B6 8E) 2.0i 20V (130 Hp) Multitronic – Full specifications
General information
Brand Audi
Model A4
Generation A4 Avant (B6 8E)
Modification (Engine) 2.0i 20V (130 Hp) Multitronic
Start of production 2001 year
End of production 2004 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 10.9 l/100 km
21.58 US mpg
25.92 UK mpg
9.17 km/l
Fuel consumption (economy) – extra urban 6.2 l/100 km
37.94 US mpg
45.56 UK mpg
16.13 km/l
Fuel consumption (economy) – combined 7.9 l/100 km
29.77 US mpg
35.76 UK mpg
12.66 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 10.5 sec
Acceleration 0 – 62 mph 10.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10 sec
Maximum speed 202 km/h
125.52 mph
Weight-to-power ratio 10.8 kg/Hp, 92.9 Hp/tonne
Weight-to-torque ratio 7.2 kg/Nm, 139.3 Nm/tonne
Engine specs
Power 130 Hp @ 5700 rpm.
Power per litre 65.5 Hp/l
Torque 195 Nm @ 3300 rpm.
143.82 lb.-ft. @ 3300 rpm.
Engine layout Front, Longitudinal
Engine Model/Code ALT
Engine displacement 1984 cm3
121.07 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 92.8 mm
3.65 in.
Compression ratio 10.3:1
Number of valves per cylinder 5
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 4.2 l
4.44 US qt | 3.7 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7 l
7.4 US qt | 6.16 UK qt

Space, Volume and weights
Kerb Weight 1400 kg
3086.47 lbs.
Max. weight 1950 kg
4299.01 lbs.
Max load 550 kg
1212.54 lbs.
Trunk (boot) space – minimum 442 l
15.61 cu. ft.
Trunk (boot) space – maximum 1184 l
41.81 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Dimensions
Length 4548 mm
179.06 in.
Width 1772 mm
69.76 in.
Height 1428 mm
56.22 in.
Wheelbase 2650 mm
104.33 in.
Front track 1528 mm
60.16 in.
Rear (Back) track 1526 mm
60.08 in.
Drag coefficient (Cd) 0.30
Minimum turning circle (turning diameter) 11.1 m
36.42 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox automatic transmission Multitronic
Front suspension Independent multi-link suspension
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 195/65 R15; 205/55 R16
Wheel rims size 6.5J x 15; 16
