Specifications: Audi A4 Avant (B6 8E) 2.5 TDI V6 (163 Hp) Multitronic 2002, 2003, 2004

2002 Audi A4 Avant (B6 8E) - Photo 1

Audi A4 Avant (B6 8E) 2.5 TDI V6 (163 Hp) Multitronic – Full specifications
General information
Brand Audi
Model A4
Generation A4 Avant (B6 8E)
Modification (Engine) 2.5 TDI V6 (163 Hp) Multitronic
Start of production July, 2002 year
End of production 2004 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 9.3 l/100 km
25.29 US mpg
30.37 UK mpg
10.75 km/l
Fuel consumption (economy) – extra urban 5.7 l/100 km
41.27 US mpg
49.56 UK mpg
17.54 km/l
Fuel consumption (economy) – combined 7 l/100 km
33.6 US mpg
40.35 UK mpg
14.29 km/l
Fuel Type Diesel
Acceleration 0 – 100 km/h 9.2 sec
Acceleration 0 – 62 mph 9.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.7 sec
Maximum speed 217 km/h
134.84 mph
Weight-to-power ratio 9.8 kg/Hp, 102.5 Hp/tonne
Weight-to-torque ratio 5.1 kg/Nm, 195 Nm/tonne
Engine specs
Power 163 Hp @ 4000 rpm.
Power per litre 65.3 Hp/l
Torque 310 Nm @ 1400-3600 rpm.
228.64 lb.-ft. @ 1400-3600 rpm.
Engine layout Front, Longitudinal
Engine Model/Code BDG, BFC
Engine displacement 2496 cm3
152.32 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 78.3 mm
3.08 in.
Piston Stroke 86.4 mm
3.4 in.
Compression ratio 18.5:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 5.5 l
5.81 US qt | 4.84 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 12 l
12.68 US qt | 10.56 UK qt

Space, Volume and weights
Kerb Weight 1590 kg
3505.35 lbs.
Max. weight 2140 kg
4717.89 lbs.
Max load 550 kg
1212.54 lbs.
Trunk (boot) space – minimum 442 l
15.61 cu. ft.
Trunk (boot) space – maximum 1184 l
41.81 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Dimensions
Length 4548 mm
179.06 in.
Width 1772 mm
69.76 in.
Height 1428 mm
56.22 in.
Wheelbase 2650 mm
104.33 in.
Front track 1528 mm
60.16 in.
Rear (Back) track 1526 mm
60.08 in.
Drag coefficient (Cd) 0.33
Minimum turning circle (turning diameter) 11.1 m
36.42 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox automatic transmission Multitronic
Front suspension Independent multi-link suspension
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 205/55 R16
Wheel rims size 7J x 16
