Specifications: Audi A4 Avant (B8 8K) 2.0 TFSI (180 Hp) Multitronic 2008, 2009, 2010, 2011

2009 Audi A4 Avant (B8 8K) - Photo 1

Audi A4 Avant (B8 8K) 2.0 TFSI (180 Hp) Multitronic – Full specifications
General information
Brand Audi
Model A4
Generation A4 Avant (B8 8K)
Modification (Engine) 2.0 TFSI (180 Hp) Multitronic
Start of production 2008 year
End of production 2011 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 9.8 l/100 km
24 US mpg
28.82 UK mpg
10.2 km/l
Fuel consumption (economy) – extra urban 5.9 l/100 km
39.87 US mpg
47.88 UK mpg
16.95 km/l
Fuel consumption (economy) – combined 7.3 l/100 km
32.22 US mpg
38.7 UK mpg
13.7 km/l
CO2 emissions 172 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 8.6 sec
Acceleration 0 – 62 mph 8.6 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.2 sec
Maximum speed 218 km/h
135.46 mph
Emission standard Euro 5
Weight-to-power ratio 8.5 kg/Hp, 118 Hp/tonne
Weight-to-torque ratio 4.8 kg/Nm, 209.8 Nm/tonne
Engine specs
Power 180 Hp @ 4000-6000 rpm.
Power per litre 90.7 Hp/l
Torque 320 Nm @ 1500-3900 rpm.
236.02 lb.-ft. @ 1500-3900 rpm.
Engine layout Front, Longitudinal
Engine Model/Code EA888 / CDNB
Engine displacement 1984 cm3
121.07 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 92.8 mm
3.65 in.
Compression ratio 9.6:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4.6 l
4.86 US qt | 4.05 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7 l
7.4 US qt | 6.16 UK qt

Space, Volume and weights
Kerb Weight 1525 kg
3362.05 lbs.
Max. weight 2095 kg
4618.68 lbs.
Max load 570 kg
1256.63 lbs.
Trunk (boot) space – minimum 490 l
17.3 cu. ft.
Trunk (boot) space – maximum 1430 l
50.5 cu. ft.
Fuel tank capacity 65 l
17.17 US gal | 14.3 UK gal
Max. roof load 90 kg
198.42 lbs.
Permitted trailer load with brakes (8%) 1700 kg
3747.86 lbs.
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 80 kg
176.37 lbs.
Dimensions
Length 4703 mm
185.16 in.
Width 1826 mm
71.89 in.
Height 1436 mm
56.54 in.
Wheelbase 2808 mm
110.55 in.
Front track 1564 mm
61.57 in.
Rear (Back) track 1551 mm
61.06 in.
Drag coefficient (Cd) 0.319
Minimum turning circle (turning diameter) 11.4 m
37.4 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox automatic transmission Multitronic
Front suspension Independent multi-link suspension
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/55 R16; 225/50 R17
Wheel rims size 7.5J x 16; 7.5J x 17
