Specifications: Audi A4 Avant (B8 8K) 2.0 TFSI (211 Hp) 2008, 2009, 2010, 2011

2009 Audi A4 Avant (B8 8K) - Photo 1

Audi A4 Avant (B8 8K) 2.0 TFSI (211 Hp) – Full specifications
General information
Brand Audi
Model A4
Generation A4 Avant (B8 8K)
Modification (Engine) 2.0 TFSI (211 Hp)
Start of production 2008 year
End of production 2011 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 9.1 l/100 km
25.85 US mpg
31.04 UK mpg
10.99 km/l
Fuel consumption (economy) – extra urban 5.4 l/100 km
43.56 US mpg
52.31 UK mpg
18.52 km/l
Fuel consumption (economy) – combined 6.8 l/100 km
34.59 US mpg
41.54 UK mpg
14.71 km/l
CO2 emissions 159 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 7.1 sec
Acceleration 0 – 62 mph 7.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.7 sec
Maximum speed 242 km/h
150.37 mph
Emission standard Euro 5
Weight-to-power ratio 7.1 kg/Hp, 141.1 Hp/tonne
Weight-to-torque ratio 4.3 kg/Nm, 234.1 Nm/tonne
Engine specs
Power 211 Hp @ 4300-6000 rpm.
Power per litre 106.4 Hp/l
Torque 350 Nm @ 1500-4200 rpm.
258.15 lb.-ft. @ 1500-4200 rpm.
Engine layout Front, Longitudinal
Engine Model/Code EA888 / CAEB
Engine displacement 1984 cm3
121.07 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 92.8 mm
3.65 in.
Compression ratio 9.6:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4.6 l
4.86 US qt | 4.05 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7 l
7.4 US qt | 6.16 UK qt

Space, Volume and weights
Kerb Weight 1495 kg
3295.91 lbs.
Max. weight 2065 kg
4552.55 lbs.
Max load 570 kg
1256.63 lbs.
Trunk (boot) space – minimum 490 l
17.3 cu. ft.
Trunk (boot) space – maximum 1430 l
50.5 cu. ft.
Fuel tank capacity 65 l
17.17 US gal | 14.3 UK gal
Max. roof load 90 kg
198.42 lbs.
Permitted trailer load with brakes (8%) 1700 kg
3747.86 lbs.
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 80 kg
176.37 lbs.
Dimensions
Length 4703 mm
185.16 in.
Width 1826 mm
71.89 in.
Height 1436 mm
56.54 in.
Wheelbase 2808 mm
110.55 in.
Front track 1564 mm
61.57 in.
Rear (Back) track 1551 mm
61.06 in.
Drag coefficient (Cd) 0.319
Minimum turning circle (turning diameter) 11.4 m
37.4 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent multi-link suspension
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/55 R16; 225/50 R17
Wheel rims size 7.5J x 16; 7.5J x 17
