Specifications: Audi A4 Avant (B8 8K, facelift 2011) 2.0 TDI (136 Hp) startstop 2011, 2012, 2013, 2014, 2015

2011 Audi A4 Avant (B8 8K, facelift 2011) - Photo 1

Audi A4 Avant (B8 8K, facelift 2011) 2.0 TDI (136 Hp) start/stop – Full specifications
General information
Brand Audi
Model A4
Generation A4 Avant (B8 8K, facelift 2011)
Modification (Engine) 2.0 TDI (136 Hp) start/stop
Start of production 2011 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 5.6 l/100 km
42 US mpg
50.44 UK mpg
17.86 km/l
Fuel consumption (economy) – extra urban 4.2 l/100 km
56 US mpg
67.26 UK mpg
23.81 km/l
Fuel consumption (economy) – combined 4.7 l/100 km
50.05 US mpg
60.1 UK mpg
21.28 km/l
CO2 emissions 123 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 9.6 sec
Acceleration 0 – 62 mph 9.6 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.1 sec
Maximum speed 208 km/h
129.25 mph
Emission standard Euro 5
Weight-to-power ratio 11.3 kg/Hp, 88.6 Hp/tonne
Weight-to-torque ratio 4.8 kg/Nm, 208.5 Nm/tonne
Engine specs
Power 136 Hp @ 4200 rpm.
Power per litre 69.1 Hp/l
Torque 320 Nm @ 1750-2500 rpm.
236.02 lb.-ft. @ 1750-2500 rpm.
Engine layout Front, Longitudinal
Engine Model/Code CJCB
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 16.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 5 l
5.28 US qt | 4.4 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1535 kg
3384.1 lbs.
Max. weight 2105 kg
4640.73 lbs.
Max load 570 kg
1256.63 lbs.
Trunk (boot) space – minimum 490 l
17.3 cu. ft.
Trunk (boot) space – maximum 1430 l
50.5 cu. ft.
Fuel tank capacity 63 l
16.64 US gal | 13.86 UK gal
Max. roof load 90 kg
198.42 lbs.
Permitted trailer load with brakes (8%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 80 kg
176.37 lbs.
Dimensions
Length 4699 mm
185 in.
Width 1826 mm
71.89 in.
Width including mirrors 2040 mm
80.31 in.
Height 1436 mm
56.54 in.
Wheelbase 2808 mm
110.55 in.
Front track 1564 mm
61.57 in.
Rear (Back) track 1551 mm
61.06 in.
Front overhang 862 mm
33.94 in.
Rear overhang 1029 mm
40.51 in.
Drag coefficient (Cd) 0.30
Minimum turning circle (turning diameter) 11.5 m
37.73 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent multi-link suspension
Rear suspension Independent on trapezoidal lever
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/55 R16
Wheel rims size 7.5J x 16
