Specifications: Audi A4 Avant (B9 8W, facelift 2019) 50 TDI (286 Hp) quattro Mild Hybrid tiptronic 2020, 2021, 2022, 2023

2020 Audi A4 Avant (B9 8W, facelift 2019) - Photo 1

Audi A4 Avant (B9 8W, facelift 2019) 50 TDI (286 Hp) quattro Mild Hybrid tiptronic – Full specifications
General information
Brand Audi
Model A4
Generation A4 Avant (B9 8W, facelift 2019)
Modification (Engine) 50 TDI (286 Hp) quattro Mild Hybrid tiptronic
Start of production September, 2020 year
End of production February, 2023 year
Powertrain Architecture MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV)
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Combined fuel consumption (WLTP) 6.6-7.4 l/100 km
35.64 – 31.79 US mpg
42.8 – 38.17 UK mpg
15.15 – 13.51 km/l
CO2 emissions (WLTP) 174-193 g/km
Fuel consumption (economy) – urban (NEDC, WLTP equivalent) 7.8-8.2 l/100 km
30.16 – 28.68 US mpg
36.22 – 34.45 UK mpg
12.82 – 12.2 km/l
Fuel consumption (economy) – extra urban (NEDC, WLTP equivalent) 5.0-5.3 l/100 km
47.04 – 44.38 US mpg
56.5 – 53.3 UK mpg
20 – 18.87 km/l
Fuel consumption (economy) – combined (NEDC, WLTP equivalent) 6.0-6.3 l/100 km
39.2 – 37.34 US mpg
47.08 – 44.84 UK mpg
16.67 – 15.87 km/l
CO2 emissions (NEDC, WLTP equivalent) 158-167 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 5.3 sec
Acceleration 0 – 62 mph 5.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 5 sec
Maximum speed 250 km/h
155.34 mph
Emission standard Euro 6d-ISC-FCM
Weight-to-power ratio 6.2 kg/Hp, 160.2 Hp/tonne
Weight-to-torque ratio 2.9 kg/Nm, 347.3 Nm/tonne
Engine specs
Power 286 Hp @ 3500-4000 rpm.
Power per litre 96.4 Hp/l
Torque 620 Nm @ 1750-3000 rpm.
457.29 lb.-ft. @ 1750-3000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code DMGA
Engine displacement 2967 cm3
181.06 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 83 mm
3.27 in.
Piston Stroke 91.4 mm
3.6 in.
Compression ratio 16.3:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 6.1 l
6.45 US qt | 5.37 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 15.2 l
16.06 US qt | 13.37 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1785 kg
3935.25 lbs.
Max. weight 2385 kg
5258.02 lbs.
Max load 600 kg
1322.77 lbs.
Trunk (boot) space – minimum 495 l
17.48 cu. ft.
Trunk (boot) space – maximum 1495 l
52.8 cu. ft.
Fuel tank capacity 58 l
15.32 US gal | 12.76 UK gal
AdBlue tank 12 l
3.17 US gal | 2.64 UK gal
Max. roof load 90 kg
198.42 lbs.
Permitted trailer load with brakes (8%) 2100 kg
4629.71 lbs.
Permitted trailer load with brakes (12%) 1900 kg
4188.78 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 80 kg
176.37 lbs.
Dimensions
Length 4762 mm
187.48 in.
Width 1847 mm
72.72 in.
Width including mirrors 2022 mm
79.61 in.
Height 1460 mm
57.48 in.
Wheelbase 2820 mm
111.02 in.
Front track 1572 mm
61.89 in.
Rear (Back) track 1555 mm
61.22 in.
Front overhang 899 mm
35.39 in.
Rear overhang 1043 mm
41.06 in.
Drag coefficient (Cd) 0.28
Minimum turning circle (turning diameter) 11.6 m
38.06 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) and the electric motor permanently drive the four wheels of the car with the ability to work only in mixed mode.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 8 gears, automatic transmission tiptronic
Front suspension Independent multi-link suspension
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/50 R17
Wheel rims size 7.5 J x 17
