Specifications: Audi A4 (B5, Typ 8D) 1.6i (101 Hp) 1994, 1995, 1996, 1997, 1998, 1999

1995 Audi A4 (B5, Typ 8D) - Photo 1

Audi A4 (B5, Typ 8D) 1.6i (101 Hp) – Full specifications
General information
Brand Audi
Model A4
Generation A4 (B5, Typ 8D)
Modification (Engine) 1.6i (101 Hp)
Start of production November, 1994 year
End of production 1999 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 11.3 l/100 km
20.82 US mpg
25 UK mpg
8.85 km/l
Fuel consumption (economy) – extra urban 6 l/100 km
39.2 US mpg
47.08 UK mpg
16.67 km/l
Fuel consumption (economy) – combined 7.5 l/100 km
31.36 US mpg
37.66 UK mpg
13.33 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 11.9 sec
Acceleration 0 – 62 mph 11.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 11.3 sec
Maximum speed 191 km/h
118.68 mph
Emission standard Euro 2
Weight-to-power ratio 11.6 kg/Hp, 86.3 Hp/tonne
Weight-to-torque ratio 8.4 kg/Nm, 119.7 Nm/tonne
Engine specs
Power 101 Hp @ 5600 rpm.
Power per litre 63.3 Hp/l
Torque 140 Nm @ 3800 rpm.
103.26 lb.-ft. @ 3800 rpm.
Engine layout Front, Longitudinal
Engine Model/Code ADP, AHL, ANA, ARM
Engine displacement 1595 cm3
97.33 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 77.4 mm
3.05 in.
Compression ratio 10.3:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain SOHC
Engine oil capacity 3.5 l
3.7 US qt | 3.08 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.5 l
7.93 US qt | 6.6 UK qt

Space, Volume and weights
Kerb Weight 1170 kg
2579.41 lbs.
Max. weight 1720 kg
3791.95 lbs.
Max load 550 kg
1212.54 lbs.
Trunk (boot) space – minimum 440 l
15.54 cu. ft.
Fuel tank capacity 62 l
16.38 US gal | 13.64 UK gal
Dimensions
Length 4479 mm
176.34 in.
Width 1733 mm
68.23 in.
Height 1415 mm
55.71 in.
Wheelbase 2617 mm
103.03 in.
Front track 1498 mm
58.98 in.
Rear (Back) track 1479 mm
58.23 in.
Drag coefficient (Cd) 0.31
Minimum turning circle (turning diameter) 11.1 m
36.42 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent multi-link suspension
Rear suspension Suspension with traction connecting levers
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 195/65 R15
Wheel rims size 15
