Specifications: Audi A4 (B9 8W) 2.0 TFSI ultra (190 Hp) S tronic 2015, 2016, 2017, 2018

2016 Audi A4 (B9 8W) - Photo 1

Audi A4 (B9 8W) 2.0 TFSI ultra (190 Hp) S tronic – Full specifications
General information
Brand Audi
Model A4
Generation A4 (B9 8W)
Modification (Engine) 2.0 TFSI ultra (190 Hp) S tronic
Start of production 2015 year
End of production 2018 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 6.2-6.6 l/100 km
37.94 – 35.64 US mpg
45.56 – 42.8 UK mpg
16.13 – 15.15 km/l
Fuel consumption (economy) – extra urban 4-4.7 l/100 km
58.8 – 50.05 US mpg
70.62 – 60.1 UK mpg
25 – 21.28 km/l
Fuel consumption (economy) – combined 4.8-5.4 l/100 km
49 – 43.56 US mpg
58.85 – 52.31 UK mpg
20.83 – 18.52 km/l
CO2 emissions 109-122 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 7.3 sec
Acceleration 0 – 62 mph 7.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.9 sec
Maximum speed 240 km/h
149.13 mph
Emission standard Euro 6
Weight-to-power ratio 7.4 kg/Hp, 135.2 Hp/tonne
Weight-to-torque ratio 4.4 kg/Nm, 227.8 Nm/tonne
Engine specs
Power 190 Hp @ 4200-6000 rpm.
Power per litre 95.8 Hp/l
Torque 320 Nm @ 1450-4200 rpm.
236.02 lb.-ft. @ 1450-4200 rpm.
Engine layout Front, Longitudinal
Engine Model/Code EA888 / CVKB
Engine displacement 1984 cm3
121.07 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 92.8 mm
3.65 in.
Compression ratio 11.65:1
Number of valves per cylinder 4
Fuel injection system Direct injection and Multi-port manifold injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 5.2 l
5.49 US qt | 4.58 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7.8 l
8.24 US qt | 6.86 UK qt
Engine systems Start & Stop System

Space, Volume and weights
Kerb Weight 1405 kg
3097.49 lbs.
Max. weight 1985 kg
4376.18 lbs.
Max load 580 kg
1278.68 lbs.
Trunk (boot) space – minimum 480 l
16.95 cu. ft.
Trunk (boot) space – maximum 965 l
34.08 cu. ft.
Fuel tank capacity 54 l
14.27 US gal | 11.88 UK gal
Max. roof load 90 kg
198.42 lbs.
Permitted trailer load with brakes (8%) 1700 kg
3747.86 lbs.
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 740 kg
1631.42 lbs.
Permitted towbar download 80 kg
176.37 lbs.
Dimensions
Length 4726 mm
186.06 in.
Width 1842 mm
72.52 in.
Width including mirrors 2022 mm
79.61 in.
Height 1427 mm
56.18 in.
Wheelbase 2820 mm
111.02 in.
Front track 1572 mm
61.89 in.
Rear (Back) track 1555 mm
61.22 in.
Front overhang 880 mm
34.65 in.
Rear overhang 1026 mm
40.39 in.
Drag coefficient (Cd) 0.27
Minimum turning circle (turning diameter) 11.6 m
38.06 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 7 gears, automatic transmission S tronic
Front suspension Independent multi-link suspension, Transverse stabilizer
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/50 R17; 245/40 R18; 245/35 R19
Wheel rims size 7.5J x 17; 8J x 18; 8.5J x 19
