Specifications: Audi A4 Cabriolet (B7 8H) 3.2 FSI V6 (255 Hp) 2005, 2006, 2007, 2008

2006 Audi A4 Cabriolet (B7 8H) - Photo 1

Audi A4 Cabriolet (B7 8H) 3.2 FSI V6 (255 Hp) – Full specifications
General information
Brand Audi
Model A4
Generation A4 Cabriolet (B7 8H)
Modification (Engine) 3.2 FSI V6 (255 Hp)
Start of production 2005 year
End of production 2008 year
Powertrain Architecture Internal Combustion engine
Body type Cabriolet
Seats 4
Doors 2
Performance specs
Fuel consumption (economy) – urban 13.8 l/100 km
17.04 US mpg
20.47 UK mpg
7.25 km/l
Fuel consumption (economy) – extra urban 7.2 l/100 km
32.67 US mpg
39.23 UK mpg
13.89 km/l
Fuel consumption (economy) – combined 9.6 l/100 km
24.5 US mpg
29.43 UK mpg
10.42 km/l
CO2 emissions 230 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 7.2 sec
Acceleration 0 – 62 mph 7.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.8 sec
Maximum speed 250 km/h
155.34 mph
Emission standard Euro 4
Weight-to-power ratio 6.5 kg/Hp, 153.6 Hp/tonne
Weight-to-torque ratio 5 kg/Nm, 198.8 Nm/tonne
Engine specs
Power 255 Hp @ 6500 rpm.
Power per litre 81.7 Hp/l
Torque 330 Nm @ 3250 rpm.
243.4 lb.-ft. @ 3250 rpm.
Engine layout Front, Longitudinal
Engine Model/Code AUK, BKH
Engine displacement 3123 cm3
190.58 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 84.5 mm
3.33 in.
Piston Stroke 92.8 mm
3.65 in.
Compression ratio 12.5:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 6.2 l
6.55 US qt | 5.46 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 12 l
12.68 US qt | 10.56 UK qt

Space, Volume and weights
Kerb Weight 1660 kg
3659.67 lbs.
Max. weight 2140 kg
4717.89 lbs.
Max load 480 kg
1058.22 lbs.
Trunk (boot) space – minimum 246 l
8.69 cu. ft.
Trunk (boot) space – maximum 315 l
11.12 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Permitted trailer load with brakes (8%) 1800 kg
3968.32 lbs.
Permitted trailer load with brakes (12%) 1700 kg
3747.86 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 80 kg
176.37 lbs.
Dimensions
Length 4573 mm
180.04 in.
Width 1777 mm
69.96 in.
Height 1391 mm
54.76 in.
Wheelbase 2650 mm
104.33 in.
Front track 1522 mm
59.92 in.
Rear (Back) track 1518 mm
59.76 in.
Drag coefficient (Cd) 0.31
Minimum turning circle (turning diameter) 11.1 m
36.42 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent multi-link suspension
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 215/55 R16
Wheel rims size 7J x 16
