Specifications: Audi A5 Cabriolet (8F7, facelift 2011) 2.0 TFSI (225 Hp) 2013, 2014, 2015, 2016

2012 Audi A5 Cabriolet (8F7, facelift 2011) - Photo 1

Audi A5 Cabriolet (8F7, facelift 2011) 2.0 TFSI (225 Hp) – Full specifications
General information
Brand Audi
Model A5
Generation A5 Cabriolet (8F7, facelift 2011)
Modification (Engine) 2.0 TFSI (225 Hp)
Start of production April, 2013 year
End of production 2016 year
Powertrain Architecture Internal Combustion engine
Body type Cabriolet
Seats 4
Doors 2
Performance specs
Fuel consumption (economy) – urban 8.1-8.6 l/100 km
29.04 – 27.35 US mpg
34.87 – 32.85 UK mpg
12.35 – 11.63 km/l
Fuel consumption (economy) – extra urban 5.2-5.9 l/100 km
45.23 – 39.87 US mpg
54.32 – 47.88 UK mpg
19.23 – 16.95 km/l
Fuel consumption (economy) – combined 6.3-6.9 l/100 km
37.34 – 34.09 US mpg
44.84 – 40.94 UK mpg
15.87 – 14.49 km/l
CO2 emissions 144-157 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 7.4 sec
Acceleration 0 – 62 mph 7.4 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7 sec
Maximum speed 245 km/h
152.24 mph
Emission standard Euro 6
Weight-to-power ratio 7.2 kg/Hp, 138 Hp/tonne
Weight-to-torque ratio 4.7 kg/Nm, 214.7 Nm/tonne
Engine specs
Power 225 Hp @ 4500-6250 rpm.
Power per litre 113.4 Hp/l
Torque 350 Nm @ 1500-4500 rpm.
258.15 lb.-ft. @ 1500-4500 rpm.
Engine layout Front, Longitudinal
Engine Model/Code EA888 / CNCD
Engine displacement 1984 cm3
121.07 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 92.8 mm
3.65 in.
Compression ratio 9.6:1
Number of valves per cylinder 4
Fuel injection system Direct injection and Multi-port manifold injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4.6 l
4.86 US qt | 4.05 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Start & Stop System

Space, Volume and weights
Kerb Weight 1630 kg
3593.53 lbs.
Max. weight 2130 kg
4695.85 lbs.
Max load 500 kg
1102.31 lbs.
Trunk (boot) space – minimum 320 l
11.3 cu. ft.
Trunk (boot) space – maximum 750 l
26.49 cu. ft.
Fuel tank capacity 63 l
16.64 US gal | 13.86 UK gal
Permitted trailer load with brakes (8%) 1700 kg
3747.86 lbs.
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 80 kg
176.37 lbs.
Dimensions
Length 4626 mm
182.13 in.
Width 1854 mm
72.99 in.
Width including mirrors 2020 mm
79.53 in.
Height 1383 mm
54.45 in.
Wheelbase 2751 mm
108.31 in.
Front track 1590 mm
62.6 in.
Rear (Back) track 1577 mm
62.09 in.
Front overhang 861 mm
33.9 in.
Rear overhang 1014 mm
39.92 in.
Drag coefficient (Cd) 0.31
Minimum turning circle (turning diameter) 11.4 m
37.4 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent multi-link suspension, Transverse stabilizer
Rear suspension Independent on trapezoidal lever, Transverse stabilizer
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/50 R17; 245/40 R18; 255/35 R19
Wheel rims size 7.5J x 17; 8.5J x 18; 8.5J x 19; 9J x 19
