Specifications: Audi A5 Sportback (8TA) 2.0 TFSI (180 Hp) 2009, 2010, 2011

2010 Audi A5 Sportback (8TA) - Photo 1

Audi A5 Sportback (8TA) 2.0 TFSI (180 Hp) – Full specifications
General information
Brand Audi
Model A5
Generation A5 Sportback (8TA)
Modification (Engine) 2.0 TFSI (180 Hp)
Start of production 2009 year
End of production 2011 year
Powertrain Architecture Internal Combustion engine
Body type Fastback
Seats 4
Doors 5
Performance specs
Fuel consumption (economy) – urban 9.4 l/100 km
25.02 US mpg
30.05 UK mpg
10.64 km/l
Fuel consumption (economy) – extra urban 5.9 l/100 km
39.87 US mpg
47.88 UK mpg
16.95 km/l
Fuel consumption (economy) – combined 7.2 l/100 km
32.67 US mpg
39.23 UK mpg
13.89 km/l
CO2 emissions 152 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 8.1 sec
Acceleration 0 – 62 mph 8.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.7 sec
Maximum speed 233 km/h
144.78 mph
Emission standard Euro 5
Weight-to-power ratio 8.3 kg/Hp, 120 Hp/tonne
Weight-to-torque ratio 4.7 kg/Nm, 213.3 Nm/tonne
Engine specs
Power 180 Hp @ 4000-6000 rpm.
Power per litre 90.7 Hp/l
Torque 320 Nm @ 1500-3900 rpm.
236.02 lb.-ft. @ 1500-3900 rpm.
Engine layout Front, Longitudinal
Engine Model/Code CAEA, CDNB
Engine displacement 1984 cm3
121.07 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 92.8 mm
3.65 in.
Compression ratio 9.6:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4.6 l
4.86 US qt | 4.05 UK qt
Engine oil specification Log in to see.Log in to see.

Space, Volume and weights
Kerb Weight 1500 kg
3306.93 lbs.
Max. weight 2030 kg
4475.38 lbs.
Max load 530 kg
1168.45 lbs.
Trunk (boot) space – minimum 480 l
16.95 cu. ft.
Trunk (boot) space – maximum 980 l
34.61 cu. ft.
Fuel tank capacity 65 l
17.17 US gal | 14.3 UK gal
Max. roof load 90 kg
198.42 lbs.
Permitted trailer load with brakes (8%) 1700 kg
3747.86 lbs.
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 80 kg
176.37 lbs.
Dimensions
Length 4711 mm
185.47 in.
Width 1854 mm
72.99 in.
Height 1391 mm
54.76 in.
Wheelbase 2810 mm
110.63 in.
Front track 1590 mm
62.6 in.
Rear (Back) track 1575 mm
62.01 in.
Drag coefficient (Cd) 0.29
Minimum turning circle (turning diameter) 11.5 m
37.73 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent multi-link suspension
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/50 R17
Wheel rims size 7.5J x 17
