Specifications: Audi A6 (4B,C5) 2.5 TDI V6 (150 Hp) Tiptronic 1997, 1998, 1999, 2000, 2001

1998 Audi A6 (4B,C5) - Photo 1

Audi A6 (4B,C5) 2.5 TDI V6 (150 Hp) Tiptronic – Full specifications
General information
Brand Audi
Model A6
Generation A6 (4B,C5)
Modification (Engine) 2.5 TDI V6 (150 Hp) Tiptronic
Start of production November, 1997 year
End of production May, 2001 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 11.6 l/100 km
20.3 US mpg
24.4 UK mpg
8.6 km/l
Fuel consumption (economy) – extra urban 5.8 l/100 km
40.6 US mpg
48.7 UK mpg
17.2 km/l
Fuel consumption (economy) – combined 7.9 l/100 km
29.8 US mpg
35.8 UK mpg
12.7 km/l
CO2 emissions 213 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 10.7 sec
Acceleration 0 – 62 mph 10.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.2 sec
Maximum speed 212 km/h
131.73 mph
Emission standard Euro 2
Weight-to-power ratio 10.3 kg/Hp, 97.4 Hp/tonne
Weight-to-torque ratio 5 kg/Nm, 201.3 Nm/tonne
Engine specs
Power 150 Hp @ 4000 rpm.
Power per litre 60.1 Hp/l
Torque 310 Nm @ 1500-3200 rpm.
228.64 lb.-ft. @ 1500-3200 rpm.
Engine layout Front, Longitudinal
Engine Model/Code AFB, AKN
Engine displacement 2496 cm3
152.32 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 78.3 mm
3.08 in.
Piston Stroke 86.4 mm
3.4 in.
Compression ratio 19.5:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 5.5 l
5.81 US qt | 4.84 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6 l
6.34 US qt | 5.28 UK qt

Space, Volume and weights
Kerb Weight 1540 kg
3395.12 lbs.
Max. weight 2120 kg
4673.8 lbs.
Max load 580 kg
1278.68 lbs.
Trunk (boot) space – maximum 551 l
19.46 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (8%) 1900 kg
4188.78 lbs.
Permitted trailer load with brakes (12%) 1800 kg
3968.32 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 85 kg
187.39 lbs.
Dimensions
Length 4796 mm
188.82 in.
Width 1810 mm
71.26 in.
Height 1452 mm
57.17 in.
Wheelbase 2760 mm
108.66 in.
Front track 1540 mm
60.63 in.
Rear (Back) track 1569 mm
61.77 in.
Drag coefficient (Cd) 0.28
Minimum turning circle (turning diameter) 11.68 m
38.32 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, automatic transmission Tiptronic
Front suspension Independent multi-link suspension
Rear suspension Semi-independent, coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 205/60 R15
Wheel rims size 6J x 15
