Specifications: Audi A6 Avant (4F,C6 facelift 2008) 2.0 TDI (170 Hp) DPF 2008, 2009, 2010, 2011

2009 Audi A6 Avant (4F,C6 facelift 2008) - Photo 1

Audi A6 Avant (4F,C6 facelift 2008) 2.0 TDI (170 Hp) DPF – Full specifications
General information
Brand Audi
Model A6
Generation A6 Avant (4F,C6 facelift 2008)
Modification (Engine) 2.0 TDI (170 Hp) DPF
Start of production August, 2008 year
End of production 2011 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 7.5 l/100 km
31.4 US mpg
37.7 UK mpg
13.3 km/l
Fuel consumption (economy) – extra urban 4.8 l/100 km
49 US mpg
58.9 UK mpg
20.8 km/l
Fuel consumption (economy) – combined 5.8 l/100 km
40.6 US mpg
48.7 UK mpg
17.2 km/l
CO2 emissions 152 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 9.2 sec
Acceleration 0 – 62 mph 9.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.7 sec
Maximum speed 221 km/h
137.32 mph
Emission standard Euro 5
Weight-to-power ratio 9.7 kg/Hp, 103 Hp/tonne
Weight-to-torque ratio 4.7 kg/Nm, 212.1 Nm/tonne
Engine specs
Power 170 Hp @ 4200 rpm.
Power per litre 86.4 Hp/l
Torque 350 Nm @ 1750-2500 rpm.
258.15 lb.-ft. @ 1750-2500 rpm.
Engine layout Front, Longitudinal
Engine Model/Code CAHA
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 18:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4.3 l
4.54 US qt | 3.78 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1650 kg
3637.63 lbs.
Max. weight 2280 kg
5026.54 lbs.
Max load 630 kg
1388.91 lbs.
Trunk (boot) space – minimum 565 l
19.95 cu. ft.
Trunk (boot) space – maximum 1660 l
58.62 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (8%) 1800 kg
3968.32 lbs.
Permitted trailer load with brakes (12%) 1600 kg
3527.4 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 85 kg
187.39 lbs.
Dimensions
Length 4927 mm
193.98 in.
Width 1855 mm
73.03 in.
Height 1463 mm
57.6 in.
Wheelbase 2843 mm
111.93 in.
Front track 1612 mm
63.46 in.
Rear (Back) track 1618 mm
63.7 in.
Drag coefficient (Cd) 0.31
Minimum turning circle (turning diameter) 11.9 m
39.04 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent multi-link suspension
Rear suspension Independent on trapezoidal lever
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 205/60 R16
Wheel rims size 7J x 16
