Specifications: Audi A6 Avant (4G, C7) 2.8 FSI V6 (204 Hp) Multitronic 2011, 2012, 2013, 2014

2011 Audi A6 Avant (4G, C7) - Photo 1

Audi A6 Avant (4G, C7) 2.8 FSI V6 (204 Hp) Multitronic – Full specifications
General information
Brand Audi
Model A6
Generation A6 Avant (4G, C7)
Modification (Engine) 2.8 FSI V6 (204 Hp) Multitronic
Start of production 2011 year
End of production 2014 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 9.6 l/100 km
24.5 US mpg
29.4 UK mpg
10.4 km/l
Fuel consumption (economy) – extra urban 6.1 l/100 km
38.6 US mpg
46.3 UK mpg
16.4 km/l
Fuel consumption (economy) – combined 7.4 l/100 km
31.8 US mpg
38.2 UK mpg
13.5 km/l
CO2 emissions 172 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 7.7 sec
Acceleration 0 – 62 mph 7.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.3 sec
Maximum speed 240 km/h
149.13 mph
Emission standard Euro 5
Weight-to-power ratio 7.9 kg/Hp, 126.7 Hp/tonne
Weight-to-torque ratio 5.8 kg/Nm, 173.9 Nm/tonne
Engine specs
Power 204 Hp @ 5250-6500 rpm.
Power per litre 73.6 Hp/l
Torque 280 Nm @ 3000-5000 rpm.
206.52 lb.-ft. @ 3000-5000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code CHVA, CNYA
Engine displacement 2773 cm3
169.22 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 84.5 mm
3.33 in.
Piston Stroke 82.4 mm
3.24 in.
Compression ratio 12:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Naturally aspirated engine
Engine oil capacity 6.8 l
7.19 US qt | 5.98 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 12 l
12.68 US qt | 10.56 UK qt

Space, Volume and weights
Kerb Weight 1610 kg
3549.44 lbs.
Max. weight 2190 kg
4828.12 lbs.
Max load 580 kg
1278.68 lbs.
Trunk (boot) space – minimum 565 l
19.95 cu. ft.
Trunk (boot) space – maximum 1680 l
59.33 cu. ft.
Fuel tank capacity 65 l
17.17 US gal | 14.3 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 85 kg
187.39 lbs.
Dimensions
Length 4926 mm
193.94 in.
Width 1874 mm
73.78 in.
Width including mirrors 2086 mm
82.13 in.
Height 1468 mm
57.8 in.
Wheelbase 2912 mm
114.65 in.
Front track 1874 mm
73.78 in.
Rear (Back) track 1618 mm
63.7 in.
Front overhang 912 mm
35.91 in.
Rear overhang 1102 mm
43.39 in.
Ride height (ground clearance) 117 mm
4.61 in.
Drag coefficient (Cd) 0.26
Minimum turning circle (turning diameter) 11.9 m
39.04 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox automatic transmission Multitronic
Front suspension Independent multi-link suspension
Rear suspension Independent on trapezoidal lever
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/60 R16
Wheel rims size 7.5J x 16
