Specifications: Audi A6 Avant (4G, C7) 3.0 TDI V6 (204 Hp) 2011, 2012, 2013, 2014

2011 Audi A6 Avant (4G, C7) - Photo 1

Audi A6 Avant (4G, C7) 3.0 TDI V6 (204 Hp) – Full specifications
General information
Brand Audi
Model A6
Generation A6 Avant (4G, C7)
Modification (Engine) 3.0 TDI V6 (204 Hp)
Start of production 2011 year
End of production 2014 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 6.5 l/100 km
36.2 US mpg
43.5 UK mpg
15.4 km/l
Fuel consumption (economy) – extra urban 4.4 l/100 km
53.5 US mpg
64.2 UK mpg
22.7 km/l
Fuel consumption (economy) – combined 5.3 l/100 km
44.4 US mpg
53.3 UK mpg
18.9 km/l
CO2 emissions 139 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 7.9 sec
Acceleration 0 – 62 mph 7.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.5 sec
Maximum speed 232 km/h
144.16 mph
Emission standard Euro 5
Weight-to-power ratio 8.3 kg/Hp, 120.7 Hp/tonne
Weight-to-torque ratio 3.8 kg/Nm, 266.3 Nm/tonne
Engine specs
Power 204 Hp @ 3750-4500 rpm.
Power per litre 68.8 Hp/l
Torque 450 Nm @ 1250-3500 rpm.
331.9 lb.-ft. @ 1250-3500 rpm.
Engine layout Front, Longitudinal
Engine Model/Code CLAA, CLAB
Engine displacement 2967 cm3
181.06 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 83 mm
3.27 in.
Piston Stroke 91.4 mm
3.6 in.
Compression ratio 17:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 6.4 l
6.76 US qt | 5.63 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 11.5 l
12.15 US qt | 10.12 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1690 kg
3725.81 lbs.
Max. weight 2320 kg
5114.72 lbs.
Max load 630 kg
1388.91 lbs.
Trunk (boot) space – minimum 565 l
19.95 cu. ft.
Trunk (boot) space – maximum 1680 l
59.33 cu. ft.
Fuel tank capacity 65 l
17.17 US gal | 14.3 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (8%) 1900 kg
4188.78 lbs.
Permitted trailer load with brakes (12%) 1800 kg
3968.32 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 85 kg
187.39 lbs.
Dimensions
Length 4926 mm
193.94 in.
Width 1874 mm
73.78 in.
Width including mirrors 2086 mm
82.13 in.
Height 1468 mm
57.8 in.
Wheelbase 2912 mm
114.65 in.
Front track 1874 mm
73.78 in.
Rear (Back) track 1618 mm
63.7 in.
Front overhang 912 mm
35.91 in.
Rear overhang 1102 mm
43.39 in.
Ride height (ground clearance) 117 mm
4.61 in.
Drag coefficient (Cd) 0.26
Minimum turning circle (turning diameter) 11.9 m
39.04 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent multi-link suspension
Rear suspension Independent on trapezoidal lever
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 225/60 R16
Wheel rims size 7.5J x 16
