Specifications: Audi A7 Sportback (C8) 40 TDI (204 Hp) S tronic Mild Hybrid 2018, 2019, 2020, 2021, 2022, 2023

2018 Audi A7 Sportback (C8) - Photo 1

Audi A7 Sportback (C8) 40 TDI (204 Hp) S tronic Mild Hybrid – Full specifications
General information
Brand Audi
Model A7
Generation A7 Sportback (C8)
Modification (Engine) 40 TDI (204 Hp) S tronic Mild Hybrid
Start of production 2018 year
End of production 2023 year
Powertrain Architecture MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV)
Body type Liftback
Seats 5
Doors 5
Performance specs
Combined fuel consumption (WLTP) 5.7-6.2 l/100 km
41.3 – 37.9 US mpg
49.6 – 45.6 UK mpg
17.5 – 16.1 km/l
CO2 emissions (WLTP) 149-161 g/km
Fuel consumption (economy) – urban 5.0-5.3 l/100 km
47 – 44.4 US mpg
56.5 – 53.3 UK mpg
20 – 18.9 km/l
Fuel consumption (economy) – extra urban 4.2-4.6 l/100 km
56 – 51.1 US mpg
67.3 – 61.4 UK mpg
23.8 – 21.7 km/l
Fuel consumption (economy) – combined 4.5-4.9 l/100 km
52.3 – 48 US mpg
62.8 – 57.6 UK mpg
22.2 – 20.4 km/l
CO2 emissions 117-127 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 8.3 sec
Acceleration 0 – 62 mph 8.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 7.9 sec
Maximum speed 245 km/h
152.24 mph
Emission standard Euro 6
Weight-to-power ratio 8.3 kg/Hp, 120 Hp/tonne
Weight-to-torque ratio 4.3 kg/Nm, 235.3 Nm/tonne
Engine specs
Power 204 Hp @ 3750-4200 rpm.
Power per litre 103.7 Hp/l
Torque 400 Nm @ 1750-3000 rpm.
295.02 lb.-ft. @ 1750-3000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code DFBA
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 5.5 l
5.81 US qt | 4.84 UK qt
Engine oil specification Log in to see.Log in to see.
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1700 kg
3747.86 lbs.
Trunk (boot) space – minimum 535 l
18.89 cu. ft.
Fuel tank capacity 63 l
16.64 US gal | 13.86 UK gal
Max. roof load 100 kg
220.46 lbs.
Permitted trailer load with brakes (12%) 2000 kg
4409.25 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 95 kg
209.44 lbs.
Dimensions
Length 4969 mm
195.63 in.
Width 1908 mm
75.12 in.
Width including mirrors 2118 mm
83.39 in.
Height 1422 mm
55.98 in.
Wheelbase 2926 mm
115.2 in.
Front track 1651 mm
65 in.
Rear (Back) track 1637 mm
64.45 in.
Front overhang 927 mm
36.5 in.
Rear overhang 1116 mm
43.94 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) and electric motor drive the front wheels of the car with the ability to work only in mixed mode.
Drive wheel Front wheel drive
Number of gears and type of gearbox 7 gears, automatic transmission S tronic
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
