Specifications: Audi Coupe (B3 89) 2.0 20V (160 Hp) quattro 1990, 1991

1989 Audi Coupe (B3 89) - Photo 1

Audi Coupe (B3 89) 2.0 20V (160 Hp) quattro – Full specifications
General information
Brand Audi
Model Coupe
Generation Coupe (B3 89)
Modification (Engine) 2.0 20V (160 Hp) quattro
Start of production August, 1990 year
End of production July, 1991 year
Powertrain Architecture Internal Combustion engine
Body type Coupe
Seats 5
Doors 2
Performance specs
Fuel consumption (economy) – urban 12 l/100 km
19.6 US mpg
23.54 UK mpg
8.33 km/l
Fuel consumption (economy) – extra urban 9 l/100 km
26.13 US mpg
31.39 UK mpg
11.11 km/l
Fuel consumption (economy) – combined 11 l/100 km
21.38 US mpg
25.68 UK mpg
9.09 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 8.5 sec
Acceleration 0 – 62 mph 8.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.1 sec
Maximum speed 240 km/h
149.13 mph
Weight-to-power ratio 8.4 kg/Hp, 118.5 Hp/tonne
Weight-to-torque ratio 6.9 kg/Nm, 144.4 Nm/tonne
Engine specs
Power 160 Hp @ 5900 rpm.
Power per litre 80.2 Hp/l
Torque 195 Nm
143.82 lb.-ft.
Engine layout Front, Longitudinal
Engine Model/Code NM
Engine displacement 1994 cm3
121.68 cu. in.
Number of cylinders 5
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 77.4 mm
3.05 in.
Compression ratio 10.3:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 4.5 l
4.76 US qt | 3.96 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8 l
8.45 US qt | 7.04 UK qt

Space, Volume and weights
Kerb Weight 1350 kg
2976.24 lbs.
Max. weight 1750 kg
3858.09 lbs.
Max load 400 kg
881.85 lbs.
Trunk (boot) space – minimum 232 l
8.19 cu. ft.
Trunk (boot) space – maximum 522 l
18.43 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Dimensions
Length 4366 mm
171.89 in.
Width 1716 mm
67.56 in.
Height 1370 mm
53.94 in.
Wheelbase 2550 mm
100.39 in.
Front track 1455 mm
57.28 in.
Rear (Back) track 1435 mm
56.5 in.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Independent type McPherson
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 205/60 R15
Wheel rims size 15
