Specifications: Audi Coupe (B3 89) 2.3 E 20V (167 Hp) 1990, 1991

1989 Audi Coupe (B3 89) - Photo 1

Audi Coupe (B3 89) 2.3 E 20V (167 Hp) – Full specifications
General information
Brand Audi
Model Coupe
Generation Coupe (B3 89)
Modification (Engine) 2.3 E 20V (167 Hp)
Start of production 1990 year
End of production 1991 year
Powertrain Architecture Internal Combustion engine
Body type Coupe
Seats 5
Doors 2
Performance specs
Fuel consumption (economy) – urban 13.2 l/100 km
17.82 US mpg
21.4 UK mpg
7.58 km/l
Fuel consumption (economy) – extra urban 7 l/100 km
33.6 US mpg
40.35 UK mpg
14.29 km/l
Fuel consumption (economy) – combined 8.5 l/100 km
27.67 US mpg
33.23 UK mpg
11.76 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 8.6 sec
Acceleration 0 – 62 mph 8.6 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.2 sec
Maximum speed 220 km/h
136.7 mph
Weight-to-power ratio 7.2 kg/Hp, 139.2 Hp/tonne
Weight-to-torque ratio 5.6 kg/Nm, 180 Nm/tonne
Engine specs
Power 167 Hp @ 6000 rpm.
Power per litre 72.3 Hp/l
Torque 216 Nm @ 4500 rpm.
159.31 lb.-ft. @ 4500 rpm.
Engine layout Front, Longitudinal
Engine Model/Code 7A
Engine displacement 2309 cm3
140.9 cu. in.
Number of cylinders 5
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 86.4 mm
3.4 in.
Compression ratio 10.3:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 4.5 l
4.76 US qt | 3.96 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8 l
8.45 US qt | 7.04 UK qt

Space, Volume and weights
Kerb Weight 1200 kg
2645.55 lbs.
Max. weight 1660 kg
3659.67 lbs.
Max load 460 kg
1014.13 lbs.
Trunk (boot) space – minimum 296 l
10.45 cu. ft.
Trunk (boot) space – maximum 596 l
21.05 cu. ft.
Fuel tank capacity 70 l
18.49 US gal | 15.4 UK gal
Dimensions
Length 4366 mm
171.89 in.
Width 1716 mm
67.56 in.
Height 1375 mm
54.13 in.
Wheelbase 2556 mm
100.63 in.
Front track 1455 mm
57.28 in.
Rear (Back) track 1445 mm
56.89 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 5 gears, manual transmission
Front suspension Wishbone
Rear suspension Several levers and rods
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 205/60 R15
