Specifications: Audi Q3 II (F3) 35 TDI (150 Hp) S tronic 2018, 2019, 2020

2019 Audi Q3 II (F3) - Photo 1

Audi Q3 II (F3) 35 TDI (150 Hp) S tronic – Full specifications
General information
Brand Audi
Model Q3
Generation Q3 II (F3)
Modification (Engine) 35 TDI (150 Hp) S tronic
Start of production 2018 year
End of production 2020 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 5
Doors 5
Performance specs
Combined fuel consumption (WLTP) 5.8-6.3 l/100 km
40.6 – 37.3 US mpg
48.7 – 44.8 UK mpg
17.2 – 15.9 km/l
CO2 emissions (WLTP) 153-166 g/km
Fuel consumption (economy) – urban 5.4 l/100 km
43.6 US mpg
52.3 UK mpg
18.5 km/l
Fuel consumption (economy) – extra urban 4.3-4.5 l/100 km
54.7 – 52.3 US mpg
65.7 – 62.8 UK mpg
23.3 – 22.2 km/l
Fuel consumption (economy) – combined 4.7-4.9 l/100 km
50 – 48 US mpg
60.1 – 57.6 UK mpg
21.3 – 20.4 km/l
CO2 emissions 123-128 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 9.2 sec
Acceleration 0 – 62 mph 9.2 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 8.7 sec
Maximum speed 207 km/h
128.62 mph
Emission standard Euro 6d – TEMP
Weight-to-power ratio 10.5 kg/Hp, 94.9 Hp/tonne
Weight-to-torque ratio 4.6 kg/Nm, 215.2 Nm/tonne
Engine specs
Power 150 Hp @ 3500-4000 rpm.
Power per litre 76.2 Hp/l
Torque 340 Nm @ 1750-3000 rpm.
250.77 lb.-ft. @ 1750-3000 rpm.
Engine layout Front, Transverse
Engine Model/Code DFGA
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 16.2:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 4.7 l
4.97 US qt | 4.14 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8 l
8.45 US qt | 7.04 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1580 kg
3483.3 lbs.
Max. weight 2155 kg
4750.96 lbs.
Max load 575 kg
1267.66 lbs.
Trunk (boot) space – minimum 530 l
18.72 cu. ft.
Trunk (boot) space – maximum 1525 l
53.85 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
AdBlue tank 18 l
4.76 US gal | 3.96 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (8%) 2000 kg
4409.25 lbs.
Permitted trailer load with brakes (12%) 2000 kg
4409.25 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 90 kg
198.42 lbs.
Dimensions
Length 4484 mm
176.54 in.
Width 1856 mm
73.07 in.
Width including mirrors 2024 mm
79.69 in.
Height 1616 mm
63.62 in.
Wheelbase 2680 mm
105.51 in.
Front track 1584 mm
62.36 in.
Rear (Back) track 1576 mm
62.05 in.
Front overhang 896 mm
35.28 in.
Rear overhang 908 mm
35.75 in.
Drag coefficient (Cd) 0.32
Minimum turning circle (turning diameter) 11.8 m
38.71 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 7 gears, automatic transmission S tronic
Front suspension Independent type McPherson
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 215/65 R17
Wheel rims size 6.5J x 17
