Specifications: Audi Q5 I (8R, facelift 2012) 2.0 TDI (150 Hp) 2012, 2013, 2014

2013 Audi Q5 I (8R, facelift 2012) - Photo 1

Audi Q5 I (8R, facelift 2012) 2.0 TDI (150 Hp) – Full specifications
General information
Brand Audi
Model Q5
Generation Q5 I (8R, facelift 2012)
Modification (Engine) 2.0 TDI (150 Hp)
Start of production June, 2012 year
End of production 2014 year
Powertrain Architecture Internal Combustion engine
Body type SUV
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 6 l/100 km
39.2 US mpg
47.1 UK mpg
16.7 km/l
Fuel consumption (economy) – extra urban 4.9 l/100 km
48 US mpg
57.6 UK mpg
20.4 km/l
Fuel consumption (economy) – combined 5.3 l/100 km
44.4 US mpg
53.3 UK mpg
18.9 km/l
CO2 emissions 139 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 10.9 sec
Acceleration 0 – 62 mph 10.9 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 10.4 sec
Maximum speed 192 km/h
119.3 mph
Emission standard Euro 5
Weight-to-power ratio 11.2 kg/Hp, 89.3 Hp/tonne
Weight-to-torque ratio 5.3 kg/Nm, 190.5 Nm/tonne
Engine specs
Power 150 Hp @ 4200 rpm.
Power per litre 76.2 Hp/l
Torque 320 Nm @ 1750-2500 rpm.
236.02 lb.-ft. @ 1750-2500 rpm.
Engine layout Front, Longitudinal
Engine Model/Code CJCD, CSUA
Engine displacement 1968 cm3
120.09 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 81 mm
3.19 in.
Piston Stroke 95.5 mm
3.76 in.
Compression ratio 16:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 4.7 l
4.97 US qt | 4.14 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 9 l
9.51 US qt | 7.92 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1680 kg
3703.77 lbs.
Max. weight 2260 kg
4982.45 lbs.
Max load 580 kg
1278.68 lbs.
Trunk (boot) space – minimum 540 l
19.07 cu. ft.
Trunk (boot) space – maximum 1560 l
55.09 cu. ft.
Fuel tank capacity 75 l
19.81 US gal | 16.5 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (8%) 2000 kg
4409.25 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 100 kg
220.46 lbs.
Dimensions
Length 4629 mm
182.24 in.
Width 1898 mm
74.72 in.
Width including mirrors 2089 mm
82.24 in.
Height 1655 mm
65.16 in.
Wheelbase 2807 mm
110.51 in.
Front track 1617 mm
63.66 in.
Rear (Back) track 1614 mm
63.54 in.
Front overhang 895 mm
35.24 in.
Rear overhang 927 mm
36.5 in.
Ride height (ground clearance) 200 mm
7.87 in.
Minimum turning circle (turning diameter) 11.6 m
38.06 ft.
Approach angle 25°
Ramp-over (brakeover) angle 17.6°
Climb angle 31°
Wading depth 500 mm
19.69 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Independent multi-link suspension
Rear suspension Independent on trapezoidal lever
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 235/65 R 17
Wheel rims size 8J x 17
