Specifications: Audi R8 II Coupe (4S) 5.2 FSI V10 (540 Hp) quattro S tronic 2015, 2016, 2017, 2018

2015 Audi R8 II Coupe (4S) - Photo 1

Audi R8 II Coupe (4S) 5.2 FSI V10 (540 Hp) quattro S tronic – Full specifications
General information
Brand Audi
Model R8
Generation R8 II Coupe (4S)
Modification (Engine) 5.2 FSI V10 (540 Hp) quattro S tronic
Start of production 2015 year
End of production 2018 year
Powertrain Architecture Internal Combustion engine
Body type Coupe
Seats 2
Doors 2
Performance specs
Fuel consumption (economy) – urban 16.7 l/100 km
14.08 US mpg
16.92 UK mpg
5.99 km/l
Fuel consumption (economy) – extra urban 8.4 l/100 km
28 US mpg
33.63 UK mpg
11.9 km/l
Fuel consumption (economy) – combined 11.4 l/100 km
20.63 US mpg
24.78 UK mpg
8.77 km/l
CO2 emissions 272 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 3.5 sec
Acceleration 0 – 62 mph 3.5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 3.3 sec
Maximum speed 320 km/h
198.84 mph
Emission standard Euro 6
Weight-to-power ratio 3 kg/Hp, 338.6 Hp/tonne
Weight-to-torque ratio 3 kg/Nm, 338.6 Nm/tonne
Engine specs
Power 540 Hp @ 7800 rpm.
Power per litre 103.8 Hp/l
Torque 540 Nm @ 6500 rpm.
398.28 lb.-ft. @ 6500 rpm.
Engine layout Middle, Longitudinal
Engine Model/Code CSPB
Engine displacement 5204 cm3
317.57 cu. in.
Number of cylinders 10
Engine configuration V-engine
Cylinder Bore 84.5 mm
3.33 in.
Piston Stroke 92.8 mm
3.65 in.
Compression ratio 12.5:1
Number of valves per cylinder 4
Fuel injection system Direct injection and Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 8.3 l
8.77 US qt | 7.3 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 24.7 l
26.1 US qt | 21.73 UK qt
Engine systems Start & Stop System
Cylinder deactivation system

Space, Volume and weights
Kerb Weight 1595 kg
3516.37 lbs.
Max. weight 1895 kg
4177.76 lbs.
Max load 300 kg
661.39 lbs.
Trunk (boot) space – minimum 112 l
3.96 cu. ft.
Fuel tank capacity 83 l
21.93 US gal | 18.26 UK gal
Dimensions
Length 4426 mm
174.25 in.
Width 1940 mm
76.38 in.
Width including mirrors 2037 mm
80.2 in.
Height 1240 mm
48.82 in.
Wheelbase 2650 mm
104.33 in.
Front track 1638 mm
64.49 in.
Rear (Back) track 1599 mm
62.95 in.
Front overhang 994 mm
39.13 in.
Rear overhang 782 mm
30.79 in.
Drag coefficient (Cd) 0.36
Minimum turning circle (turning diameter) 11.2 m
36.75 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels permanently, and the front wheels are driven through an electrically or mechanically operated clutch if necessary.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 7 gears, automatic transmission S tronic
Front suspension Coil spring, Double wishbone, Transverse stabilizer
Rear suspension Double wishbone, Transverse stabilizer, Coil spring
Front brakes Ventilated discs, 365×34 mm
Rear brakes Ventilated discs, 356×32 mm
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size Front wheel tires: 245/35 R19; 245/30 R20
Rear wheel tires: 295/35 R19; 305/30 R20
Wheel rims size Front wheel rims: 8.5J x 19; 8.5J x 20
Rear wheel rims: 11J x 19; 11J x 20
