Specifications: Audi R8 Spyder (42) GT 5.2 FSI V10 (560 Hp) quattro R tronic 2011, 2012

2010 Audi R8 Spyder (42) - Photo 1

Audi R8 Spyder (42) GT 5.2 FSI V10 (560 Hp) quattro R tronic – Full specifications
General information
Brand Audi
Model R8
Generation R8 Spyder (42)
Modification (Engine) GT 5.2 FSI V10 (560 Hp) quattro R tronic
Start of production June, 2011 year
End of production October, 2012 year
Powertrain Architecture Internal Combustion engine
Body type Cabriolet
Seats 2
Doors 2
Performance specs
Fuel consumption (economy) – urban 21.5 l/100 km
10.94 US mpg
13.14 UK mpg
4.65 km/l
Fuel consumption (economy) – extra urban 10.2 l/100 km
23.06 US mpg
27.69 UK mpg
9.8 km/l
Fuel consumption (economy) – combined 14.2 l/100 km
16.56 US mpg
19.89 UK mpg
7.04 km/l
CO2 emissions 332 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 3.8 sec
Acceleration 0 – 62 mph 3.8 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 3.6 sec
Maximum speed 317 km/h
196.97 mph
Emission standard Euro 5
Weight-to-power ratio 2.9 kg/Hp, 341.5 Hp/tonne
Weight-to-torque ratio 3 kg/Nm, 329.3 Nm/tonne
Engine specs
Power 560 Hp @ 8000 rpm.
Power per litre 107.6 Hp/l
Torque 540 Nm @ 6500 rpm.
398.28 lb.-ft. @ 6500 rpm.
Maximum engine speed 8700 rpm.
Engine layout Rear, Longitudinal
Engine Model/Code CMPA
Engine displacement 5204 cm3
317.57 cu. in.
Number of cylinders 10
Engine configuration V-engine
Cylinder Bore 84.5 mm
3.33 in.
Piston Stroke 92.8 mm
3.65 in.
Compression ratio 12.5:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 8.3 l
8.77 US qt | 7.3 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 25 l
26.42 US qt | 22 UK qt

Space, Volume and weights
Kerb Weight 1640 kg
3615.58 lbs.
Max. weight 1940 kg
4276.97 lbs.
Max load 300 kg
661.39 lbs.
Trunk (boot) space – minimum 100 l
3.53 cu. ft.
Fuel tank capacity 80 l
21.13 US gal | 17.6 UK gal
Dimensions
Length 4434 mm
174.57 in.
Width 1904 mm
74.96 in.
Width including mirrors 2029 mm
79.88 in.
Height 1244 mm
48.98 in.
Wheelbase 2650 mm
104.33 in.
Front track 1638 mm
64.49 in.
Rear (Back) track 1595 mm
62.8 in.
Front overhang 999 mm
39.33 in.
Rear overhang 785 mm
30.91 in.
Drag coefficient (Cd) 0.37
Minimum turning circle (turning diameter) 11.8 m
38.71 ft.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 6 gears, automatic transmission R tronic
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 235/35 R19; 295/30 R19
Wheel rims size 8.5J x 19; 11J x 19
