Specifications: Audi S4 Avant (4A,C4) 4.2 V8 (280 Hp) quattro 1992, 1993, 1994

1992 Audi S4 Avant (4A,C4) - Photo 1

Audi S4 Avant (4A,C4) 4.2 V8 (280 Hp) quattro – Full specifications
General information
Brand Audi
Model S4
Generation S4 Avant (4A,C4)
Modification (Engine) 4.2 V8 (280 Hp) quattro
Start of production October, 1992 year
End of production July, 1994 year
Powertrain Architecture Internal Combustion engine
Body type Station wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 18.9 l/100 km
12.45 US mpg
14.95 UK mpg
5.29 km/l
Fuel consumption (economy) – extra urban 9.3 l/100 km
25.29 US mpg
30.37 UK mpg
10.75 km/l
Fuel consumption (economy) – combined 11.3 l/100 km
20.82 US mpg
25 UK mpg
8.85 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 6.6 sec
Acceleration 0 – 62 mph 6.6 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.3 sec
Maximum speed 247 km/h
153.48 mph
Weight-to-power ratio 6.2 kg/Hp, 161.8 Hp/tonne
Weight-to-torque ratio 4.3 kg/Nm, 231.2 Nm/tonne
Engine specs
Power 280 Hp @ 5800 rpm.
Power per litre 67.1 Hp/l
Torque 400 Nm @ 4000 rpm.
295.02 lb.-ft. @ 4000 rpm.
Engine layout Front, Longitudinal
Engine Model/Code ABH
Engine displacement 4172 cm3
254.59 cu. in.
Number of cylinders 8
Engine configuration V-engine
Cylinder Bore 84.5 mm
3.33 in.
Piston Stroke 93 mm
3.66 in.
Compression ratio 10.6:1
Number of valves per cylinder 4
Fuel injection system Multi-port manifold injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 7.5 l
7.93 US qt | 6.6 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 8.5 l
8.98 US qt | 7.48 UK qt

Space, Volume and weights
Kerb Weight 1730 kg
3814 lbs.
Max. weight 2280 kg
5026.54 lbs.
Max load 550 kg
1212.54 lbs.
Trunk (boot) space – minimum 390 l
13.77 cu. ft.
Trunk (boot) space – maximum 1310 l
46.26 cu. ft.
Fuel tank capacity 80 l
21.13 US gal | 17.6 UK gal
Dimensions
Length 4790 mm
188.58 in.
Width 1805 mm
71.06 in.
Height 1422 mm
55.98 in.
Wheelbase 2692 mm
105.98 in.
Front track 1569 mm
61.77 in.
Rear (Back) track 1534 mm
60.39 in.
Drag coefficient (Cd) 0.36
Minimum turning circle (turning diameter) 11.4 m
37.4 ft.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Spring Strut
Rear suspension Coil spring
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 225/50 R16
Wheel rims size 16
