Specifications: Audi S5 Sportback (8T) 3.0 TFSI V6 (333 Hp) quattro S tronic 2010, 2011

2010 Audi S5 Sportback (8T) - Photo 1

Audi S5 Sportback (8T) 3.0 TFSI V6 (333 Hp) quattro S tronic – Full specifications
General information
Brand Audi
Model S5
Generation S5 Sportback (8T)
Modification (Engine) 3.0 TFSI V6 (333 Hp) quattro S tronic
Start of production January, 2010 year
End of production 2011 year
Powertrain Architecture Internal Combustion engine
Body type Fastback
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) – urban 13.5 l/100 km
17.42 US mpg
20.92 UK mpg
7.41 km/l
Fuel consumption (economy) – extra urban 7 l/100 km
33.6 US mpg
40.35 UK mpg
14.29 km/l
Fuel consumption (economy) – combined 9.4 l/100 km
25.02 US mpg
30.05 UK mpg
10.64 km/l
CO2 emissions 315 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 5.4 sec
Acceleration 0 – 62 mph 5.4 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 5.1 sec
Maximum speed 250 km/h
155.34 mph
Emission standard Euro 5
Weight-to-power ratio 5.3 kg/Hp, 189.7 Hp/tonne
Weight-to-torque ratio 4 kg/Nm, 250.7 Nm/tonne
Engine specs
Power 333 Hp @ 5500-7000 rpm.
Power per litre 111.2 Hp/l
Torque 440 Nm @ 2900-5300 rpm.
324.53 lb.-ft. @ 2900-5300 rpm.
Engine layout Front, Longitudinal
Engine Model/Code CAKA
Engine displacement 2995 cm3
182.77 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 84.5 mm
3.33 in.
Piston Stroke 89 mm
3.5 in.
Compression ratio 10.3:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Supercharger, Intercooler
Valvetrain DOHC
Engine oil capacity 6.2 l
6.55 US qt | 5.46 UK qt
Engine oil specification Log in to see.Log in to see.

Space, Volume and weights
Kerb Weight 1755 kg
3869.11 lbs.
Max. weight 2285 kg
5037.56 lbs.
Max load 530 kg
1168.45 lbs.
Trunk (boot) space – minimum 480 l
16.95 cu. ft.
Trunk (boot) space – maximum 980 l
34.61 cu. ft.
Fuel tank capacity 64 l
16.91 US gal | 14.08 UK gal
Max. roof load 90 kg
198.42 lbs.
Permitted trailer load with brakes (8%) 2100 kg
4629.71 lbs.
Permitted trailer load with brakes (12%) 1900 kg
4188.78 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 80 kg
176.37 lbs.
Dimensions
Length 4713 mm
185.55 in.
Width 1854 mm
72.99 in.
Width including mirrors 1981 mm
77.99 in.
Height 1382 mm
54.41 in.
Wheelbase 2811 mm
110.67 in.
Front track 1588 mm
62.52 in.
Rear (Back) track 1575 mm
62.01 in.
Drag coefficient (Cd) 0.30
Minimum turning circle (turning diameter) 11.5 m
37.73 ft.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 7 gears, automatic transmission S tronic
Front suspension Independent multi-link suspension
Rear suspension Independent on trapezoidal lever
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 245/40 R18
Wheel rims size 8.5J x 18
