Specifications: Audi S6 (C8) 3.0 TDI V6 (344 Hp) Mild Hybrid quattro tiptronic 2020, 2021, 2022, 2023

2020 Audi S6 (C8) - Photo 1

Audi S6 (C8) 3.0 TDI V6 (344 Hp) Mild Hybrid quattro tiptronic – Full specifications
General information
Brand Audi
Model S6
Generation S6 (C8)
Modification (Engine) 3.0 TDI V6 (344 Hp) Mild Hybrid quattro tiptronic
Start of production November, 2020 year
End of production May, 2023 year
Powertrain Architecture MHEV (Mild Hybrid Electric Vehicle, power-assist hybrid, battery-assisted hybrid vehicles, BAHV)
Body type Sedan
Seats 5
Doors 4
Performance specs
Combined fuel consumption (WLTP) 6.9-7.3 l/100 km
34.09 – 32.22 US mpg
40.94 – 38.7 UK mpg
14.49 – 13.7 km/l
CO2 emissions (WLTP) 182-191 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 5 sec
Acceleration 0 – 62 mph 5 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 4.8 sec
Maximum speed 250 km/h, Electronically limited
155.34 mph
Emission standard Euro 6d-ISC-FCM
Weight-to-power ratio 5.7 kg/Hp, 176 Hp/tonne
Weight-to-torque ratio 2.8 kg/Nm, 358.1 Nm/tonne
Electric cars and hybrids specs
Gross battery capacity 0.5 kWh
Battery voltage 48 V
Battery technology Lithium-ion (Li-Ion)
Battery location Under the trunk
Recuperation output 8 kW
Internal combustion engine specs
Power 344 Hp @ 3850-4000 rpm.
Power per litre 115.9 Hp/l
Torque 700 Nm @ 1750-3250 rpm.
516.29 lb.-ft. @ 1750-3250 rpm.
Engine layout Front, Longitudinal
Engine Model/Code EA897evo3 / DMKD
Engine displacement 2967 cm3
181.06 cu. in.
Number of cylinders 6
Engine configuration V-engine
Cylinder Bore 83 mm
3.27 in.
Piston Stroke 91.4 mm
3.6 in.
Compression ratio 15.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Turbocharger and Electric Powered Compressor, Intercooler
Valvetrain DOHC
Engine oil capacity 6.1 l
6.45 US qt | 5.37 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 16.7 l
17.65 US qt | 14.69 UK qt
Engine systems Start & Stop System
Particulate filter

Space, Volume and weights
Kerb Weight 1955 kg
4310.04 lbs.
Max. weight 2590 kg
5709.97 lbs.
Max load 635 kg
1399.94 lbs.
Trunk (boot) space – minimum 520 l
18.36 cu. ft.
Fuel tank capacity 63 l
16.64 US gal | 13.86 UK gal
AdBlue tank 22 l
5.81 US gal | 4.84 UK gal
Max. roof load 90 kg
198.42 lbs.
Permitted trailer load with brakes (8%) 2100 kg
4629.71 lbs.
Permitted trailer load with brakes (12%) 2100 kg
4629.71 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 95 kg
209.44 lbs.
Dimensions
Length 4954 mm
195.04 in.
Width 1886 mm
74.25 in.
Width including mirrors 2110 mm
83.07 in.
Height 1446 mm
56.93 in.
Wheelbase 2928 mm
115.28 in.
Front track 1620 mm
63.78 in.
Rear (Back) track 1603 mm
63.11 in.
Front overhang 924 mm
36.38 in.
Rear overhang 1102 mm
43.39 in.
Drag coefficient (Cd) 0.28
Minimum turning circle (turning diameter) 12.1 m
39.7 ft.
Approach angle 13.9°
Departure angle 12.8°
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) and the electric motor permanently drive the four wheels of the car with the ability to work only in mixed mode.
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 8 gears, automatic transmission tiptronic
Front suspension Independent multi-link suspension
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs, 400 mm
Rear brakes Ventilated discs, 350 mm
Assisting systems ABS (Anti-lock braking system)
4-wheel steering (4WS, active rear steering)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 255/40 R20
Wheel rims size 8.5J x 20
