Specifications: Audi TT RS Coupe (8J, facelift 2010) 2.5 TFSI plus (360 Hp) quattro S tronic 2011, 2012, 2013, 2014

2010 Audi TT RS Coupe (8J, facelift 2010) - Photo 1

Audi TT RS Coupe (8J, facelift 2010) 2.5 TFSI plus (360 Hp) quattro S tronic – Full specifications
General information
Brand Audi
Model TT
Generation TT RS Coupe (8J, facelift 2010)
Modification (Engine) 2.5 TFSI plus (360 Hp) quattro S tronic
Start of production May, 2011 year
End of production 2014 year
Powertrain Architecture Internal Combustion engine
Body type Coupe
Seats 4
Doors 3
Performance specs
Fuel consumption (economy) – urban 12.3 l/100 km
19.1 US mpg
23 UK mpg
8.1 km/l
Fuel consumption (economy) – extra urban 6.3 l/100 km
37.3 US mpg
44.8 UK mpg
15.9 km/l
Fuel consumption (economy) – combined 8.5 l/100 km
27.7 US mpg
33.2 UK mpg
11.8 km/l
CO2 emissions 197 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 4.1 sec
Acceleration 0 – 62 mph 4.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 3.9 sec
Maximum speed 280 km/h
173.98 mph
Emission standard Euro 5
Weight-to-power ratio 4.1 kg/Hp, 244.1 Hp/tonne
Weight-to-torque ratio 3.2 kg/Nm, 315.3 Nm/tonne
Engine specs
Power 360 Hp @ 5500-6700 rpm.
Power per litre 145.2 Hp/l
Torque 465 Nm @ 1650-5400 rpm.
342.97 lb.-ft. @ 1650-5400 rpm.
Engine layout Front, Transverse
Engine Model/Code CEPB
Engine displacement 2480 cm3
151.34 cu. in.
Number of cylinders 5
Engine configuration Inline
Cylinder Bore 82.5 mm
3.25 in.
Piston Stroke 92.8 mm
3.65 in.
Compression ratio 10:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Turbocharger, Intercooler
Valvetrain DOHC
Engine oil capacity 5.7 l
6.02 US qt | 5.02 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 10 l
10.57 US qt | 8.8 UK qt

Space, Volume and weights
Kerb Weight 1475 kg
3251.82 lbs.
Max. weight 1875 kg
4133.67 lbs.
Max load 400 kg
881.85 lbs.
Trunk (boot) space – minimum 290 l
10.24 cu. ft.
Trunk (boot) space – maximum 700 l
24.72 cu. ft.
Fuel tank capacity 60 l
15.85 US gal | 13.2 UK gal
Dimensions
Length 4198 mm
165.28 in.
Width 1842 mm
72.52 in.
Width including mirrors 1952 mm
76.85 in.
Height 1342 mm
52.83 in.
Wheelbase 2468 mm
97.17 in.
Front track 1555 mm
61.22 in.
Rear (Back) track 1546 mm
60.87 in.
Front overhang 911 mm
35.87 in.
Rear overhang 819 mm
32.24 in.
Drag coefficient (Cd) 0.32
Minimum turning circle (turning diameter) 10.96 m
35.96 ft.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 7 gears, automatic transmission S tronic
Front suspension Independent, type McPherson with coil spring and anti-roll bar
Rear suspension Independent multi-link spring suspension with stabilizer
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 245/40 R18
Wheel rims size 9J x 18
