Specifications: BAIC BJ 2020 2.4 (106 Hp) 1989, 1990, 1991, 1992, 1993, 1994, 1995, 1996, 1997, 1998, 1999, 2000, 2001, 2002, 2003, 2004, 2005

1989 BAIC BJ 2020 - Photo 1

BAIC BJ 2020 2.4 (106 Hp) – Full specifications
General information
Brand BAIC
Model BJ 2020
Generation BJ 2020
Modification (Engine) 2.4 (106 Hp)
Start of production 1989 year
End of production 2005 year
Powertrain Architecture Internal Combustion engine
Body type Off-road vehicle
Seats 5
Doors 5
Performance specs
Fuel Type Petrol (Gasoline)
Maximum speed 125 km/h
77.67 mph
Weight-to-power ratio 14.9 kg/Hp, 67.1 Hp/tonne
Weight-to-torque ratio 8.8 kg/Nm, 113.9 Nm/tonne
Engine specs
Power 106 Hp @ 4800 rpm.
Power per litre 43.3 Hp/l
Torque 180 Nm @ 3000 rpm.
132.76 lb.-ft. @ 3000 rpm.
Engine layout Front, Longitudinal
Engine displacement 2446 cm3
149.26 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 92 mm
3.62 in.
Piston Stroke 92 mm
3.62 in.
Compression ratio 7.6:1
Number of valves per cylinder 2
Fuel injection system Carburettor
Engine aspiration Naturally aspirated engine
Valvetrain OHC

Space, Volume and weights
Kerb Weight 1580 kg
3483.3 lbs.
Max. weight 2015 kg
4442.31 lbs.
Max load 435 kg
959.01 lbs.
Fuel tank capacity 76 l
20.08 US gal | 16.72 UK gal
Dimensions
Length 4070 mm
160.24 in.
Width 1780 mm
70.08 in.
Height 1940 mm
76.38 in.
Wheelbase 2300 mm
90.55 in.
Front track 1500 mm
59.06 in.
Rear (Back) track 1500 mm
59.06 in.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 4 gears, manual transmission
Front suspension Leaf spring
Rear suspension Leaf spring
Front brakes Disc
Rear brakes Drum
Assisting systems ABS (Anti-lock braking system)
Tires size 215/80 R16
Wheel rims size 6J x 16
