Specifications: Bentley Arnage R 6.7 i V8 16V (405 Hp) 2002, 2003, 2004, 2005

2002 Bentley Arnage R - Photo 1

Bentley Arnage R 6.7 i V8 16V (405 Hp) – Full specifications
General information
Brand Bentley
Model Arnage
Generation Arnage R
Modification (Engine) 6.7 i V8 16V (405 Hp)
Start of production 2002 year
End of production 2005 year
Powertrain Architecture Internal Combustion engine
Body type Sedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) – urban 30.7 l/100 km
7.7 US mpg
9.2 UK mpg
3.3 km/l
Fuel consumption (economy) – extra urban 14.8 l/100 km
15.9 US mpg
19.1 UK mpg
6.8 km/l
Fuel consumption (economy) – combined 20.6 l/100 km
11.4 US mpg
13.7 UK mpg
4.9 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 6.3 sec
Acceleration 0 – 62 mph 6.3 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6 sec
Maximum speed 250 km/h
155.34 mph
Weight-to-power ratio 6.4 kg/Hp, 156.7 Hp/tonne
Weight-to-torque ratio 3.1 kg/Nm, 323 Nm/tonne
Engine specs
Power 405 Hp @ 4000 rpm.
Power per litre 60 Hp/l
Torque 835 Nm @ 3250 rpm.
615.86 lb.-ft. @ 3250 rpm.
Engine layout Front, Longitudinal
Engine Model/Code L410MT22
Engine displacement 6750 cm3
411.91 cu. in.
Number of cylinders 8
Engine configuration V-engine
Cylinder Bore 104.1 mm
4.1 in.
Piston Stroke 99.01 mm
3.9 in.
Compression ratio 7.8:1
Number of valves per cylinder 2
Fuel injection system Multi-port manifold injection
Engine aspiration Turbocharger, Intercooler
Engine oil capacity 9.4 l
9.93 US qt | 8.27 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 20 l
21.13 US qt | 17.6 UK qt

Space, Volume and weights
Kerb Weight 2585 kg
5698.95 lbs.
Max. weight 2970 kg
6547.73 lbs.
Max load 385 kg
848.78 lbs.
Trunk (boot) space – minimum 374 l
13.21 cu. ft.
Fuel tank capacity 100 l
26.42 US gal | 22 UK gal
Dimensions
Length 5390 mm
212.2 in.
Width 1932 mm
76.06 in.
Height 1515 mm
59.65 in.
Wheelbase 3116 mm
122.68 in.
Front track 1602 mm
63.07 in.
Rear (Back) track 1602 mm
63.07 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 4 gears, automatic transmission
Front suspension Double wishbone
Rear suspension Wishbone
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 255/55 R17
