| General information | |
|---|---|
| Brand | BMW |
| Model | 1 Series |
| Generation | 1 Series Convertible (E88) |
| Modification (Engine) | 123d (204 Hp) Steptronic |
| Start of production | 2009 year |
| End of production | 2011 year |
| Powertrain Architecture | Internal Combustion engine |
| Body type | Cabriolet |
| Seats | 4 |
| Doors | 2 |
| Performance specs | |
| Fuel consumption (economy) – urban | 7.6 l/100 km 30.9 US mpg 37.2 UK mpg 13.2 km/l |
| Fuel consumption (economy) – extra urban | 4.9 l/100 km 48 US mpg 57.6 UK mpg 20.4 km/l |
| Fuel consumption (economy) – combined | 5.9 l/100 km 39.9 US mpg 47.9 UK mpg 16.9 km/l |
| CO2 emissions | 154 g/km |
| Fuel Type | Diesel |
| Acceleration 0 – 100 km/h | 7.6 sec |
| Acceleration 0 – 62 mph | 7.6 sec |
| Acceleration 0 – 60 mph (Calculated by Auto-Data.net) | 7.2 sec |
| Maximum speed | 230 km/h 142.92 mph |
| Emission standard | Euro 5 |
| Weight-to-power ratio | 7.5 kg/Hp, 132.5 Hp/tonne |
| Weight-to-torque ratio | 3.9 kg/Nm, 259.7 Nm/tonne |
| Engine specs | |
| Power | 204 Hp @ 4400 rpm. |
| Power per litre | 102.3 Hp/l |
| Torque | 400 Nm @ 2000-2250 rpm. 295.02 lb.-ft. @ 2000-2250 rpm. |
| Engine layout | Front, Longitudinal |
| Engine Model/Code | N47D20D |
| Engine displacement | 1995 cm3 121.74 cu. in. |
| Number of cylinders | 4 |
| Engine configuration | Inline |
| Cylinder Bore | 84 mm 3.31 in. |
| Piston Stroke | 90 mm 3.54 in. |
| Compression ratio | 16.5:1 |
| Number of valves per cylinder | 4 |
| Fuel injection system | Diesel Commonrail |
| Engine aspiration | Twin-power turbo, Intercooler |
| Engine oil capacity | 5.2 l 5.49 US qt | 4.58 UK qt |
| Engine oil specification |  Log in to see. |
| Coolant | 7.4 l 7.82 US qt | 6.51 UK qt |
| Engine systems | Particulate filter |
|
|
|
| Space, Volume and weights | |
| Kerb Weight | 1540 kg 3395.12 lbs. |
| Max. weight | 1980 kg 4365.15 lbs. |
| Max load | 440 kg 970.03 lbs. |
| Trunk (boot) space – minimum | 260 l 9.18 cu. ft. |
| Trunk (boot) space – maximum | 305 l 10.77 cu. ft. |
| Fuel tank capacity | 51 l 13.47 US gal | 11.22 UK gal |
| Permitted trailer load with brakes (12%) | 1200 kg 2645.55 lbs. |
| Permitted trailer load without brakes | 740 kg 1631.42 lbs. |
| Permitted towbar download | 75 kg 165.35 lbs. |
| Dimensions | |
| Length | 4360 mm 171.65 in. |
| Width | 1748 mm 68.82 in. |
| Height | 1423 mm 56.02 in. |
| Wheelbase | 2660 mm 104.72 in. |
| Front track | 1474 mm 58.03 in. |
| Rear (Back) track | 1507 mm 59.33 in. |
| Ride height (ground clearance) | 140 mm 5.51 in. |
| Drag coefficient (Cd) | 0.32 |
| Minimum turning circle (turning diameter) | 10.7 m 35.1 ft. |
| Drivetrain, brakes and suspension specs | |
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
| Drive wheel | Rear wheel drive |
| Number of gears and type of gearbox | 6 gears, automatic transmission |
| Front suspension | Double wishbone |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated discs |
| Rear brakes | Ventilated discs |
| Assisting systems | ABS (Anti-lock braking system) |
| Steering type | Steering rack and pinion |
| Tires size | 205/50 R17 89W |
| Wheel rims size | 7J x 17 |
