Specifications: BMW 1 Series Hatchback 3dr (E81) 116i (122 Hp) 2007, 2008, 2009

2007 BMW 1 Series Hatchback 3dr (E81) - Photo 1

BMW 1 Series Hatchback 3dr (E81) 116i (122 Hp) – Full specifications
General information
Brand BMW
Model 1 Series
Generation 1 Series Hatchback 3dr (E81)
Modification (Engine) 116i (122 Hp)
Start of production 2007 year
End of production 2009 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 4
Doors 3
Performance specs
Fuel consumption (economy) – urban 7.9 l/100 km
29.8 US mpg
35.8 UK mpg
12.7 km/l
Fuel consumption (economy) – extra urban 5.1 l/100 km
46.1 US mpg
55.4 UK mpg
19.6 km/l
Fuel consumption (economy) – combined 6.1 l/100 km
38.6 US mpg
46.3 UK mpg
16.4 km/l
CO2 emissions 143 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 10.1 sec
Acceleration 0 – 62 mph 10.1 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 9.6 sec
Maximum speed 204 km/h
126.76 mph
Emission standard Euro 5
Weight-to-power ratio 10.3 kg/Hp, 97.2 Hp/tonne
Weight-to-torque ratio 7.8 kg/Nm, 127.5 Nm/tonne
Engine specs
Power 122 Hp @ 6000 rpm.
Power per litre 76.3 Hp/l
Torque 160 Nm @ 4250 rpm.
118.01 lb.-ft. @ 4250 rpm.
Engine layout Front, Longitudinal
Engine Model/Code N43B16A
Engine displacement 1599 cm3
97.58 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 82 mm
3.23 in.
Piston Stroke 75.7 mm
2.98 in.
Compression ratio 12:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Naturally aspirated engine
Engine oil capacity 4.25 l
4.49 US qt | 3.74 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7 l
7.4 US qt | 6.16 UK qt

Space, Volume and weights
Kerb Weight 1255 kg
2766.8 lbs.
Max. weight 1755 kg
3869.11 lbs.
Max load 500 kg
1102.31 lbs.
Trunk (boot) space – minimum 330 l
11.65 cu. ft.
Trunk (boot) space – maximum 1150 l
40.61 cu. ft.
Fuel tank capacity 53 l
14 US gal | 11.66 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (12%) 1200 kg
2645.55 lbs.
Permitted trailer load without brakes 650 kg
1433 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4239 mm
166.89 in.
Width 1748 mm
68.82 in.
Height 1421 mm
55.94 in.
Wheelbase 2660 mm
104.72 in.
Front track 1484 mm
58.43 in.
Rear (Back) track 1497 mm
58.94 in.
Ride height (ground clearance) 145 mm
5.71 in.
Drag coefficient (Cd) 0.29
Minimum turning circle (turning diameter) 10.7 m
35.1 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of gears and type of gearbox 6 gears, manual transmission
Front suspension Double wishbone
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Hydraulic Steering
Tires size 195/55 R16 87 H
Wheel rims size 6.5J x 16
