Specifications: BMW 1 Series Hatchback 3dr (F21 LCI, facelift 2015) 120d (190 Hp) xDrive Steptronic 2015, 2016, 2017

2015 BMW 1 Series Hatchback 3dr (F21 LCI, facelift 2015) - Photo 1

BMW 1 Series Hatchback 3dr (F21 LCI, facelift 2015) 120d (190 Hp) xDrive Steptronic – Full specifications
General information
Brand BMW
Model 1 Series
Generation 1 Series Hatchback 3dr (F21 LCI, facelift 2015)
Modification (Engine) 120d (190 Hp) xDrive Steptronic
Start of production 2015 year
End of production 2017 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 4-5
Doors 3
Performance specs
Fuel consumption (economy) – urban 5.1 – 5.5 l/100 km
46.1 – 42.8 US mpg
55.4 – 51.4 UK mpg
19.6 – 18.2 km/l
Fuel consumption (economy) – extra urban 3.9 – 4.3 l/100 km
60.3 – 54.7 US mpg
72.4 – 65.7 UK mpg
25.6 – 23.3 km/l
Fuel consumption (economy) – combined 4.3 – 4.7 l/100 km
54.7 – 50 US mpg
65.7 – 60.1 UK mpg
23.3 – 21.3 km/l
CO2 emissions 113 – 124 g/km
Fuel Type Diesel
Acceleration 0 – 100 km/h 6.8 sec
Acceleration 0 – 62 mph 6.8 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 6.5 sec
Maximum speed 222 km/h
137.94 mph
Emission standard Euro 6
Weight-to-power ratio 7.6 kg/Hp, 131 Hp/tonne
Weight-to-torque ratio 3.6 kg/Nm, 275.9 Nm/tonne
Engine specs
Power 190 Hp @ 4000 rpm.
Power per litre 95.2 Hp/l
Torque 400 Nm @ 1750-2500 rpm.
295.02 lb.-ft. @ 1750-2500 rpm.
Engine layout Front, Longitudinal
Engine Model/Code B47D20A
Engine displacement 1995 cm3
121.74 cu. in.
Number of cylinders 4
Engine configuration Inline
Cylinder Bore 84 mm
3.31 in.
Piston Stroke 90 mm
3.54 in.
Compression ratio 16.5:1
Number of valves per cylinder 4
Fuel injection system Diesel Commonrail
Engine aspiration Twin-power turbo, Intercooler
Engine oil capacity 5 l
5.28 US qt | 4.4 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 7 l
7.4 US qt | 6.16 UK qt
Engine systems Particulate filter

Space, Volume and weights
Kerb Weight 1450 kg
3196.7 lbs.
Max. weight 2000 kg
4409.25 lbs.
Max load 550 kg
1212.54 lbs.
Trunk (boot) space – minimum 360 l
12.71 cu. ft.
Trunk (boot) space – maximum 1200 l
42.38 cu. ft.
Fuel tank capacity 52 l
13.74 US gal | 11.44 UK gal
Max. roof load 75 kg
165.35 lbs.
Permitted trailer load with brakes (12%) 1500 kg
3306.93 lbs.
Permitted trailer load without brakes 750 kg
1653.47 lbs.
Permitted towbar download 75 kg
165.35 lbs.
Dimensions
Length 4329 mm
170.43 in.
Width 1765 mm
69.49 in.
Width including mirrors 1984 mm
78.11 in.
Height 1421 mm
55.94 in.
Wheelbase 2690 mm
105.91 in.
Front track 1522 mm
59.92 in.
Rear (Back) track 1556 mm
61.26 in.
Ride height (ground clearance) 140 mm
5.51 in.
Drag coefficient (Cd) 0.31
Minimum turning circle (turning diameter) 11.3 m
37.07 ft.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 8 gears, automatic transmission Steptronic
Front suspension Double wishbone
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Disc
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 205/55 R16; 205/50 R17; 225/45 R17; 245/40 R17; 225/40 R18; 245/35 R18
Wheel rims size 7J x 16; 7J x 17; 7.5J x 17; 8J x 17; 7.5J x 18; 8J x 18
