Specifications: BMW 1 Series Hatchback 3dr (F21) M135i (320 Hp) xDrive Steptronic 2012, 2013, 2014, 2015

2012 BMW 1 Series Hatchback 3dr (F21) - Photo 1

BMW 1 Series Hatchback 3dr (F21) M135i (320 Hp) xDrive Steptronic – Full specifications
General information
Brand BMW
Model 1 Series
Generation 1 Series Hatchback 3dr (F21)
Modification (Engine) M135i (320 Hp) xDrive Steptronic
Start of production 2012 year
End of production 2015 year
Powertrain Architecture Internal Combustion engine
Body type Hatchback
Seats 4-5
Doors 3
Performance specs
Fuel consumption (economy) – urban 10.8 l/100 km
21.8 US mpg
26.2 UK mpg
9.3 km/l
Fuel consumption (economy) – extra urban 6.1 l/100 km
38.6 US mpg
46.3 UK mpg
16.4 km/l
Fuel consumption (economy) – combined 7.8 l/100 km
30.2 US mpg
36.2 UK mpg
12.8 km/l
CO2 emissions 182 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 – 100 km/h 4.7 sec
Acceleration 0 – 62 mph 4.7 sec
Acceleration 0 – 60 mph (Calculated by Auto-Data.net) 4.5 sec
Maximum speed 250 km/h
155.34 mph
Emission standard Euro 5
Weight-to-power ratio 4.7 kg/Hp, 211.2 Hp/tonne
Weight-to-torque ratio 3.4 kg/Nm, 297 Nm/tonne
Engine specs
Power 320 Hp @ 5800 rpm.
Power per litre 107.4 Hp/l
Torque 450 Nm @ 1300-4500 rpm.
331.9 lb.-ft. @ 1300-4500 rpm.
Engine layout Front, Longitudinal
Engine Model/Code N55B30A
Engine displacement 2979 cm3
181.79 cu. in.
Number of cylinders 6
Engine configuration Inline
Cylinder Bore 84 mm
3.31 in.
Piston Stroke 89.6 mm
3.53 in.
Compression ratio 10.2:1
Number of valves per cylinder 4
Fuel injection system Direct injection
Engine aspiration Twin-power turbo, Intercooler
Engine oil capacity 6.5 l
6.87 US qt | 5.72 UK qt
Engine oil specification Log in to see.Log in to see.
Coolant 6.7 l
7.08 US qt | 5.9 UK qt

Space, Volume and weights
Kerb Weight 1515 kg
3340 lbs.
Max. weight 2045 kg
4508.45 lbs.
Max load 530 kg
1168.45 lbs.
Trunk (boot) space – minimum 360 l
12.71 cu. ft.
Trunk (boot) space – maximum 1200 l
42.38 cu. ft.
Fuel tank capacity 52 l
13.74 US gal | 11.44 UK gal
Max. roof load 75 kg
165.35 lbs.
Dimensions
Length 4340 mm
170.87 in.
Width 1765 mm
69.49 in.
Height 1411 mm
55.55 in.
Wheelbase 2690 mm
105.91 in.
Front track 1512 mm
59.53 in.
Rear (Back) track 1532 mm
60.31 in.
Ride height (ground clearance) 130 mm
5.12 in.
Drag coefficient (Cd) 0.34
Minimum turning circle (turning diameter) 11.3 m
37.07 ft.
Drivetrain, brakes and suspension specs
Drive wheel All wheel drive (4×4)
Number of gears and type of gearbox 8 gears, automatic transmission Steptronic
Front suspension Double wishbone
Rear suspension Independent multi-link suspension
Front brakes Ventilated discs
Rear brakes Ventilated discs
Assisting systems ABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 225/40 R18 88Y; 245/35 R18 92Y
Wheel rims size 7.5J x 18; 8J x 18
